To configure IP Filters:
1. From the Advanced Menu, select Security > IP Filters.
2. Select a LAN Group.
3. Select a LAN IP. If the desired LAN IP is not available in the LAN IP drop-down
menu, click New IP to add an IP.
4. Select Available Rules and then move them into Applied Rules.
To select a rule, select a Category then select an available rule based on the
selected Category. Click View to view the rule settings.
If a rule is not in the list, you can create your own rule. Select User, and then click
New. The Rule Management page opens for you to create new rules. Enter Rule
Name, Protocol, Port Start, Port End, Port Map, and then click Apply.
5. Click Add to move the rule into Applied Rules.
6. To temporarily implement the changes, click Submit.
7. To make the change permanent, click Save Settings.
