Routing; Static Routing - Aztech Ethernet USB Combo Router User Manual

User Manual

Routing

Routing options include:

Static Routing

Routing Table
Static Routing
If the router is connected to more than one network, you may need to set up a static
route between them. A static route is a pre-defined pathway that network information
must travel to reach a specific host or network. You can use static routing to allow
different IP domain users to access the Internet through the router.
Static Routing
The New Destination IP is the address of the remote LAN network or host to which you
want to assign a static route. Enter the IP address of the host for which you wish to
create a static route here. For a standard Class C IP domain, the network address is the
first three fields of the New Destination IP, while the last field should be 0. The Subnet
Mask identifies which portion of an IP address is the network portion, and which portion
is the host portion. For a full Class C Subnet, the Subnet Mask is 255.255.255.0. The
Gateway IP address should be the IP address of the gateway device that allows for
contact between the Gateway and the remote network or host.
Page 70 of 92
