Features
- Transfer large data, music and photo files at Wireless speeds up to 300Mbps
- Secure your WiFi network with advanced 64/128 bit WEP, WPA, and WPA2
- Enjoy wider wireless coverage and maximum range with MIMO technology
- Share your network with portable hard drives and printers via USB
Specifications
Standards
- Wireless 802.11b/g/n
- IEEE 802.3 10/100, IEEE 802.3u
- USB 2.0 OTG
Wireless Modulation
- DBPSK / DQPSK / CCK / BPSK / QPSK / QAM-16 /
QAM-64
Wireless Frequency Range
- North America (FCC) : 2.412GHz~2.462GHz
- Europe (ETSI)
: 2.412GHz~2.472GHz
- Japan (MKK)
: 2.412GHz~2.472GHz
Wireless Max Transmit Power
- 802.11b (1 antenna) : 18 +/- 1dBm
- 802.11b (1 antenna) : 17 +/- 1dBm
- 802.11b (2 antenna) : 17 +/- 1dBm
Wireless Rate
- 11b/g: 54/48/36/24/12/9/6/11/5.5/2/1 Mbps
(Auto Rate Sensing)
- EWC/802.11n:
6, 6.5, 13, 13.5, 19.5, 26, 27, 39, 40.5, 53, 54, 58.5, 65,
78, 81, 104, 108,
117, 121.5, 130, 135, 162, 216, 243, 270,300Mbps
Environment
- Operating: 0˚C to 40˚C
- Storage: -25˚C to 70˚C
- Environment: 30% to 80% Humidity
(Non-Condensing)
Specifications are subjected to change without prior notice.
Trademarks: All trademarks or registered trademarks are the property of their respective owners.
Other Related Aztech Product
System Requirement
- Input Power
- 12V @ 1A DC
- Power Consumption - 12Watt (max)
Management
- Web-based configuration and management interface
- One button wireless configuration (WPS)
Network Support
- Static IP, Dynamic RIP routing support
- IP/TCP/UDP/ICMP/ARP Application support
- Netwrok Address Translation (NAT)
- Multi Range Port Mapping/Forwarding
- IGMP V1/2 support
- DHCP Server/Relay/client
- Dynamic DNS support
- DNS Relay Agent
- DMZ support
- PPP always on with configurable timeout
Security
- NAT for Basic Firewall Support
- Packet Filtering Firewall Support
- Stateful Packet Inspection Support
- URL Blocking Support
- Protection against Denail of Service attacks
- Password Authentication to Modem
Wireless-N Gateway to the Internet
ADSL/Cable Modem
Playstation3,
Xbox360, Wii
WL851USB - Wireless 802.11 b/g USB Adaptor
- Adopts MIMO technology for wireless rates of up to 300Mbps
- Adopts CCA™ technology which automatically avoids channel conflicts using its channel selection feature
- Support 802.11b/g/n solution in 2.4GHz frequency band
- Support Roaming technology, guarantees efficient wireless connections
- Greater flexibility to locate or move networked PCs, and Wireless connection without the cost of cabling.
- Web-site Configuration and monitoring
- Easy to install and user friendly, just Plug and Play
- With built-in antenna
- Support system Windows 2000, Windows XP and Vista OS
Share your network with
portable hard drives and
printers via USB
Up to 4 Desktops/
Notebooks with
Ethernet Connection
N
10X Faster
HW550-RT4
Desktop
IPTV with Set-top Box
VoIP Phone
Notebook
Smartphone
with WiFi
