  • Page 1 HT - 4000 Series User’s Manual Rev. A0 FCC Notes: This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions manual, may cause interference to radio communications. It has been tested and found to comply with limits for a Class A digital device pursuant to subpart J of Part 15 of FCC Rules, which are designed to provide reasonable protection against interference when operated in a commercial environment.
  • Page 2 ALERT TO OUR HONORABLE CUSTOMERS: l Please always read thoroughly all the instructions and documents delivered with the product before you do anything about it. Don’t take any premature action before you have a full understanding of the consequences. l This product contains inside a Lithium battery and maybe also a sealed type Lead acid battery if the UPS battery option is ordered.
  • Page 3: Brief Introduction

    THE USER’S MANUAL The purpose of this manual is to guide the user in the initial installation and general use of the Posiflex HT-4000 series of POS terminals. It does not explain any application software that may be supplied with it.
  • Page 4: The Standard Features

    VGA Port: There is a VGA connector for connection of external monitor with + 12 V DC power supply included. USB Ports: The HT-4000 series is equipped with 3 USB type A connectors for connection of USB (Universal Serial Bus) devices. One of the 3 ports is extended to one top edge of case for easy connection to the integrated upgrade kit SD-300.
  • Page 5: System Box Contents

    UPS Battery: 2.3 AH 12V lead acid maintenance free battery 2-in-1 Cash Drawer Control Cable: Cable CCBLA-238, when added to the optional CR port of the HT-4000 series, can be used to control two Posiflex printer drive type cash drawers.
  • Page 6: Installation Guides

    TECHNICAL ENHANCEMENTS Applicable technical enhancements in HT-4000 series include serial COM port power supply settings, RTC battery replacement, VGA port power supply setting, DRAM upgrades and adding a half length PCI adapter card (This item is possible only when no powered USB port option installed).
  • Page 7: Wireless Lan (Option)

    the hooks to show the main connection area. Note: Never press the 2 springs on the metal walls as cross marked in the picture. Carelessly pressing on these 2 springs could cause damages. The user shall be responsible for such kind of damage. Even the maintenance technician must always put a piece of clean flat foam of sufficient size in front of the system unit before pressing these 2 springs.
  • Page 8: Audio Port

    the pole for installing them to corner of back cable cover will be delivered in separate package from the system unit. Please follow the Installation Guide in package of each option. The customer display will occupy one COM port. The 2 LCD screen will occupy the VGA port in the connection area.
  • Page 9: Printer (Option)

    in between the system and the programmable keyboard. However, this should be no problem in application phase. When a KB interface barcode scanner is installed in HT-4012 or HT- 4212 (no touch panel), a connection of a normal PS/2 keyboard or the Posiflex programmable keyboard could become obligatory by some OS.
  • Page 10: Operating System Recovery

    AC POWER The power supply operating voltage must be checked to support the city power supply specification and switch selected if necessary. This must be done WITHOUT any connection to the AC power. The operating voltage selection switch is located close to the power input connector in the main connection area inside the back cable cover.
  • Page 11 system without preloaded OS is highly discouraged. Posiflex shall not be responsible for any technical support to questions arisen due to non-preloaded Part 11...
  • Page 12 UPS function module option is installed. Battery replacement: In the preloaded OS for a HT-4000 series with UPS function module option, there is a built in utility Posiflex Power Switch Manager that will indicate the UPS battery status of the battery.
  • Page 13: Led Indicators

    message like this picture appears, please replace the used up UPS battery at power off as soon as possible. Emergency treatment: The battery is constructed maintenance free and leakproof. Its storage space in HT system also provides very good protection as long as the ambient temperature remains below 30 C and the ventilation of the HT system remains free.
  • Page 14: Power On/Off Control

    status. When it lights up in orange, it means that the external AC power is standing by with the system powered off. It turns into blue when the system is powered up. When the UPS function module option and the UPS battery are installed, this LED further indicates the status of system working on battery power by flashing in blue.
  • Page 15 ready after a normal power off. For LAN wakeup, an operating caller system connected through LAN to the system is required. It also requires a qualified networking technician to check the LAN chip ID of the HT system for the caller system to wake it up.
  • Page 16 Touch Function Mouse emulation The touch panel in HT system works exactly like a standard PS/2 mouse within the (primary) screen display area when its driver is properly installed. However, if the system is running under safe mode due to a previous improper shutdown or for any other reason, most drivers are disabled in this mode and the touch panel calibration may not coincide with the mouse pointer or even completely out of work.
  • Page 17: Side Mount Upgrade Kit Sd-300

    CUSTOMER DISPLAY / 2 The optional customer display PD-2601 or the optional 2 display screen mounted on a pole at rear corner of HT system can be turned horizontally for best viewing effect in application. SIDE MOUNT UPGRADE KIT SD-300 In SD-300 mounted at right side of the touch monitor of HT system, there may be the MSR for reading a magnetic stripe card and/or the optical type finger print sensor.
  • Page 18 Peripherals” then “SiS OnChip PCI Device” and disable the item “USB 2.0 Supports”. If the powered USB ports option is installed in the HT system, please be sure to insert the USB device always to the exactly correct type of the connector.
  • Page 19 Main System Unit The main system unit is supplied. Cashier LCD display Customer display carton if an option of customer display is ordered Cashier Display Carton When the order is PST7700 or PST7730, the purchased 9” VGA mono CRT monitor will be shipped in a separate box from the main system unit.
  • Page 20 ĵ§i¨Ï¥ÎªÌ T31454 ³o¬O¥ÒÃþªº¸ê°T²£«~¡A¦b ¹Ò¤¤¨Ï¥Î®É¡A¥i¯à·|³y¦¨ ÂZ¡A¦b³oºØ±¡ªp¤U¡A¨Ï¥Î ¨D±Ä¨ú¬Y¨Ç¾A·íªº¹ïµ¦¡C Part 20...
