HT-4312
PB-4300
User's Manual
FCC Notes:
This equipment generates, uses, and can
radiate radio frequency energy and, if
not installed and used in accordance with the instructions manual,
may cause interference to radio communications. It has been
tested and found to comply with limits for a Class A digital device pursuant to subpart J
of Part 15 of FCC Rules, which are designed to provide reasonable protection against
interference when operated in a commercial environment. Operation of this equipment
in a residential area is likely to cause interference in which case the user at his own
expense will be required to take whatever measures to correct the interference.
Warranty Limits:
Warranty terminates automatically when any person other than the authorized
technicians opens the machine. The user should consult his/her dealer for the problem
happened. Warranty voids if the user does not follow the instructions in application of
this merchandise. The manufacturer is by no means responsible for any damage or
hazard caused by improper application.
About This Manual:
Posiflex has made every effort for the accuracy of the content in this manual. However,
Posiflex will assume no liability for any technical inaccuracies or editorial or other
errors or omissions contained herein, nor for direct, indirect, incidental, consequential
or otherwise damages, including without limitation loss of data or profits, resulting
from the furnishing, performance, or use of this material.
This information is provided "as is" and Posiflex Technologies, Inc. expressly
disclaims any warranties, expressed, implied or statutory, including without limitation
implied warranties of merchantability or fitness for particular purpose, good title and
against infringement.
The information in this manual contains only essential hardware concerns for general
user and is subject to change without notice. Posiflex reserves the right to alter product
designs, layouts or drivers without notification. The system integrator shall provide
applicative notices and arrangement for special options utilizing this product. The user
may find the most up to date information of the hardware from web sites:
http://www.posiflex.com or http://www.posiflex.com.tw
All data should be backed-up prior to the installation of any drive unit or storage
peripheral. Posiflex will not be responsible for any loss of data resulting from the use,
disuse or misuse of this or any other Posiflex product.
All rights are strictly reserved. No part of this documentation may be reproduced,
stored in a retrieval system, or transmitted in any form or by any means, electronic,
mechanical, photocopying, or otherwise, without prior express written consent from
Posiflex Technologies Inc. the publisher of this documentation.
© Copyright Posiflex Technologies Inc. 2007
All brand and product names and trademarks are the property of their respective holders.
P/N: 15450900010
Series
Rev. Original
Part 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HT-4312 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for POSIFLEX HT-4312 Series

  • Page 1 About This Manual: Posiflex has made every effort for the accuracy of the content in this manual. However, Posiflex will assume no liability for any technical inaccuracies or editorial or other errors or omissions contained herein, nor for direct, indirect, incidental, consequential or otherwise damages, including without limitation loss of data or profits, resulting from the furnishing, performance, or use of this material.
  • Page 2 ALERT TO OUR HONORABLE CUSTOMERS: l Please always read thoroughly all the instructions and documents delivered with the product before you do anything about it. Don’t take any premature action before you have a full understanding of the consequences. l This product contains inside a Lithium battery and maybe also a sealed type Lead acid battery if the UPS battery option is ordered.
  • Page 3: Brief Introduction

    For the HT-4312 series terminal is powered by most up to date CPU and provides a color TFT LCD screen with a resistive type touch control panel on sturdy and easily adjustable structure on top of the main unit. HT-4312/PB- 4300 series may be used as a self-content unit or as one of several terminals in a network system controlled by a “back office”...
  • Page 4: The Standard Features

    THE STANDARD FEATURES CPU + Chipset: Intel Celeron 2.0 GHz + Intel 852GM or Intel P4 2.4 GHz + Intel 852GME or above. HDD: 40 GB or above. RAM: 2 DDR DIMM, 256 MB. Ethernet Networking: The standard network port works with both 10 Base T and 100 Base T.
  • Page 5: System Box Contents

    Bar Code Scanner: Short range type (near contact) and long range type (250 mm for CD-3830) CCD scanners. POS printer: Posiflex 9 pin dot matrix impact printer or Posiflex thermal printer of RS232 serial interface, parallel interface, USB interface or even wireless interface.
  • Page 6 (This item is possible only when no powered USB port option installed). All these technical enhancement operations require purchase of applicable Technical Manual from Posiflex or consultation from Posiflex authorized dealers and should be handled only by a qualified technician.
  • Page 7: Wireless Lan (Option)

    to show the main connection area. Note: Never press the 2 springs on the metal walls as cross marked in the picture. Carelessly pressing on these 2 springs could cause damages. The user shall be responsible for such kind of damage. For the HT-4312 system even the maintenance technician must always put a piece of clean flat foam of sufficient size in front of the system unit before pressing these 2 springs.
  • Page 8: Customer Display (Option)

    10” 2 DISPLAY (OPTION) When the HT-4312 series is ordered with the 2 display monitor LM-2010 or when the LM-2010 is ordered for PB-4300 to work as the primary monitor, the monitor will be delivered in separate package from the system unit.
  • Page 9 USB port in the main connection area depending on the printer model and then connect its power adaptor. It is also possible to control a Posiflex wireless POS printer by connecting a separately purchased wireless Dongle to one of the COM ports in HT-4312/PB-4300 system.
  • Page 10 Posiflex CR-2000 or CR-2200 or CR-3100 or CR-3200 or CR-4000 or CR-4100 or CR-4210 or CR-6200 be used for best compliance. The HT-4312/PB-4300 system will directly control the cash drawer using the cash drawer port (CR) both to operate the opening mechanism and to monitor the drawer open status.
  • Page 11: Operating System Installation

    HDD, Posiflex provides recovery CD or DVD delivered with the hybrid terminal for the preloaded operating system. The System Integrator shall take care of software restoration after OS recovered. Use a Posiflex supplied USB interface external CDROM or COMBO drive for such action. Other brand CDROM or COMBO drive may require its specific driver different from what supported in the recovery CD or DVD.
  • Page 12: Before Power On

    UPS function module option is installed. Battery replacement: In the preloaded OS for a HT-4312/PB-4300 series with UPS function module option, there is a built in utility Posiflex Power Switch Manager that will indicate the UPS battery status of the battery. When an installed UPS...
  • Page 13 This may cause permanent damage to any other monitor not designed to use this facility. Please use only a Posiflex monitor designed for the HT system. Consult your dealer if you have any doubt. It is strongly advised that connection/disconnection to this port should never take place when system power is ON.
  • Page 14: Power On/Off Control

    lights up in green, the onboard LAN chip is linked. When it flashes in yellow, data transmission in LAN is in process. The LAN status indication is also observable on the LAN connector in main connection area. The LED at left indicates Power/StandBy status.
  • Page 15 The end user of the HT-4312 terminals is not supposed to install the utility drivers personally. If an optional preloaded OS is ordered, the required driver will be already installed in the preloaded OS. However, the driver will always be available over our web site: http://www.posiflex.com Part 15...
  • Page 16 Windows system for the user to maneuver versatile features of the touch terminal with a PS/2 interface touch panel controller. This program can also be obtained by download from the POSIFLEX web site. However, the installation process of this driver for Win XP and Win 2003 Server requires some careful attention to the notice messages.
  • Page 17: Customer Display

    “Posiflex USB Touch Tools” is installed in the preloaded Windows system if a USB interface touch panel controller is installed. CUSTOMER DISPLAY The optional customer display mounted on a pole at rear corner of HT-4312/PB-4300 system can be turned horizontally for best viewing effect in application.
  • Page 18 Please then pull the bottom side of front cover forward to release the bottom hooks of front cover from the chassis as indicated by hollow arrow in left picture. Now pull the left side of front cover down a little to free it from the main cover as in the pictures below.
  • Page 19 Replacing Front Cover Follow the opposite procedure as removing the front cover to replace the front cover in position. Please make sure the all hooks on front cover is well positioned into chassis. Please remember to check that the power switch is at “Off”...
  • Page 20 T31454 警告使用者 這是甲類的資訊產品,在居住的環 境 中 使 用 時 , 可 能 會 造 成 射 頻 干 擾,在這種情況下,使用者會被要 求採取某些適當的對策。 Part 20...
