HS-3114A JIVA Desktop POS
User Manual
15670900010 Ver. A0
http://www.posiflex.com
Package Contents
HS-3114A desktop POS (x 1)
24V/60W Power Adaptor (x 1)
Power cord (x 1)
3-inch wide thermal paper roll (x 1)
Paper separator for 2" thermal paper roll (x 1)
Desktop mounting kit pack (x 1)
(including 1 bottom plate, 1 desktop
mounting bracket, 4 fixing screws, and 4
plastic anchors)
User manual (x 1)
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HS-3114A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for POSIFLEX HS-3114A

Summary of Contents for POSIFLEX HS-3114A

  • Page 1 HS-3114A JIVA Desktop POS User Manual Package Contents  HS-3114A desktop POS (x 1)  24V/60W Power Adaptor (x 1)  Power cord (x 1)  3-inch wide thermal paper roll (x 1)  Paper separator for 2” thermal paper roll (x 1) ...
  • Page 2 Views of HS-3114A Front View HS-3114A P-CAP Touch & LCD Panel Fingerprint or iButton Sensors (Optional) Posiflex 2D Scanner (Optional) 3-Track Magnetic Paper Jam Rescue Stripe Reader Compartment (Optional) Power LED Indicator Printer Error Printed Paper Exit LED Indicator Printer Paper-Out...
  • Page 3 Left Side View Power Button Right Side View RFID Card Reader (Optional) Paper Roll Cover Release Lever...
  • Page 4 Bottom View Rubber Pad Rubber Pad Bottom I/O Interface Mounting holes Views of I/O Interface of HS-3114A Top I/O Interface VGA Port Micro USB OTG USB 2.0 Port Reset Button Micro SD Card Slot Bottom I/O Interface RJ-10 Cash Drawer Port...

  • Page 5: Connecting Power Adapter

    Connecting Power Adapter Please refer to the following instructions on how to connect power adapter to HS-3114A and to organize your cables. Lay your desktop POS on a level surface with its touch screen facing down as shown in the figure.
  • Page 6 Loading 2” or 3” Paper Rolls Before operating the printer, please follow the below steps to load a paper roll. To open the paper roll cover, push down the paper roll cover release lever in the direction shown in the figure. Before installing 2-inch paper roll in the thermal printer, place paper separator in the paper roll compartment by following the instructions below.
  • Page 7 To load the thermal printer with the 3-inch paper roll, just drop the thermal paper roll inside the paper roll compartment of the printer as illustrated in the figure. Unroll the thermal paper and drag the loose end of the paper till it extends towards the paper cutter.

  • Page 8: Troubleshooting Paper Jams

    Replacing POS Receipt Printer Module HS-3114A offers a quick solution to help you to replace POS receipt printer module when there is a need. Please go through the steps described below to achieve the purpose. Before proceeding the procedure, please ensure that the...
  • Page 9 After laying POS terminal on a flat surface with its bottom facing towards you, remove the screw shown by the arrow. Position the terminal with its screen facing toward you, and then push down the paper roll cover release lever to open the paper roll cover, Inside the paper roll compartment, remove the two screws indicated by the arrows.
  • Page 10 Take the new printer module which you wish to replace with, and then connect the cables to the printer control board as indicated in the following figures. Connect the CR cable to CR port on the control board. Insert the cable to the port for printer signal on the control board.
  • Page 11 Using bottom plate Please follow the steps below to install the bottom plate for HS-3114A. Take the bottom plate with the mounting bracket out of the package, and place it with its screw holes on the top in your preferred position.
  • Page 12 Please first release the mounting bracket from the bottom plate by removing two screws as shown in the figure. Mounting bracket Bottom Plate After placing the mounting bracket in your preferred mounting position, use the screw holes of the mounting bracket to drill two holes on the surface.
  • Page 13 To completely mount the desktop POS onto the table, please follow the steps below. Use the two mouting holes located on the rear of the POS to drill another two holes on the same surface. Each hole also has to be at least ”...
  • Page 14 However, it is likely that HS-3114A cannot restart or shut down normally due to the unexpected reasons. In such a case, it is suggested to initiate a shutdown...
  • Page 15 Using Fingerprint or iButton Sensors (Optional) As for access control to your computer, two optional identification mechanisms are provided and integrated in HS-3114A: The fingerprint and iButton sensors. Either will work to verify an individual’s identity. In order to allow the fingerprint sensor to function normally, you have to register your own finger first using Fingerprint Recognition Tool which is pre-installed and accessible on your desktop of your system.
  • Page 16 Self-Diagnosing your Printer The variety of diagnostic tips is provided in aim to help you efficiently troubleshoot printer problems. Please carefully go through the following descriptions to understand how each function provided works.  Self Test A self-test page, generated by Self Test function, generally contains useful information describing current printer configurations.

  • Page 17: Status Led Indicator

    Status LED Indicator After HS-3114A is powered on, it is significant to observe the status of LED indicators anytime to ensure your system functions normally. More importantly, knowing how to interpret the status indicators enables you to perform basic troubleshooting more efficiently.

  • Page 18: Specifications

    Specifications HS-3114A ALLWINNER A64 processor (Quad 4-core, 1.2 Ghz), PMIC AXP803 Memory DDR3, 2GB 8G/16G/32G eMMC (on board eMMC) Storage Device Micro SD card slot x 1 (on the top I/O plate) Power Adaptor 24V/60W 14" 1366 x 768 LCD panel or LCD Display 14"...
  • Page 19 Symbology Code 128,GS1- Databar, GS1-Databar Limited, GS1- Databar Expanded, QR Code, PDF417 ※ The product information and specifications are subject to change without prior notice. To get the detailed information on HS-3114A, please check this model from Posiflex Global Website...
  • Page 20 <MEMO>...
