HS-2210E
JIVA Desktop POS
User Manual
Product Features
Compact
The compact footprint of HS-2210E Series makes itself adaptable to a wide
range of counter styles and allows every inch of the work space usage to be
optimized, thus creating maximum profit return for the store owners. This is
what space saving is all about.
All-in-one
As an "all-in-one" solution, HS-2210E Series touch-screen terminal integrates
some of the most widely used peripherals in daily POS operation, such as 3"
thermal printer, MSR, smart card reader, and 2nd customer display, and has
the features and functionality to cater for applications in retail, hospitality,
health care, banking and more, while offering uncompromising performance.
Aesthetics
Dressed from head to toe in timeless black color, the only trend that never goes
out of style, and with stylish touches added throughout, HS-2210E Series is
not just a piece of machinery, it is an elegantly crafted piece of art that looks
right at home in any store decoration.
15600900010 Ver. Original
http://www.posiflex.com
Package Contents
HS-2210E desktop POS (x 1)
12VDC/100W power adaptor (x 1)
Power cord (x 1)
3-inch wide thermal paper roll (x 1)
Desktop mounting kit pack (x 1)
(including 4 fixing screws, 4 plastic
anchors, and 1 desktop mounting
bracket)
Desktop POS user manual (x 1)
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the HS-2210E Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for POSIFLEX HS-2210E Series

Summary of Contents for POSIFLEX HS-2210E Series

  • Page 1 Product Features Compact The compact footprint of HS-2210E Series makes itself adaptable to a wide range of counter styles and allows every inch of the work space usage to be optimized, thus creating maximum profit return for the store owners. This is what space saving is all about.
  • Page 2 Views of the HS-2210E Front View LCD Touch Screen 3-track Magnetic Stripe Reader (Optional) Smart Card Reader (Optional) Printed Paper Exit Power LED Indicator Error LED Indicator Paper-out LED Indicator Feed Button Rear View Top I/O Interface Cover Bottom I/O Interface Cover Cable Exit...
  • Page 3 Left Side View Power Button Right Side View Paper Roll Cover Release Lever RFID Card Reader (Optional)
  • Page 4 Bottom View Rubber Pad Bottom IO Interface Rubber Pad View of I/O Interface of HS-2210E Top I/O Interface uboot Button COM (DB9) Port (Accessible by technicians only) USB2.0 Port 2G/3G SIM Card Slot (Optional) Bottom I/O Interface 12VDC-IN Power Jack RJ11 Cash Drawer Port COM (DB9) Port RJ45 LAN Port...
  • Page 5 Connecting Power Adapter and I/O Cables Follow the steps listed below to open the bottom I/O-port protective cover and connect cables. Make the desktop POS lie on the surface of a desk and the LCD touch panel face down. Press the portion A with thumb and then lever the cover with forefinger in the direction B.
  • Page 6 Determine that the cover is well wedged to the wedge portions of the rear plate of the POS. Gather the I/O cables together for cable arrangement and lever down the 2 hooks of the cover to cover the I/O interface. Determine that the I/O interface is Cable out covered and the cable passes...
  • Page 7 Pull the top I/O-port protective cover in the direction A. Direction A Remove the cover. Remove the shield from the bracket of the display. Pass the connector of a cable through the cable exit of the bracket of the display.
  • Page 8 Connect the connector of the cable to the port of the customer display. Cover the portion A of the bracket with the shield. Determine that the shield covering the cable is firmly fixed onto the bracket. Align the four holes of the bracket with the four screw holes formed on the bracket-fixing portion of the top I/O interface section.
  • Page 9 Fix the cable into the concave area of the display bracket for arrangement. Screw the display bracket to the bracket-fixing portion of the top I/O interface section. Connect the connector of the cable to the port of the top I/O interface. Break the cable-exit cover.
  • Page 10 Determine that the cover is well wedged to the wedge portions of the rear plate of the POS. Push the cover to make the 2 hooks of the cover to wedge the 2 wedge portions of the rear plate of the POS. Determine that the I/O interface is covered and the cable passes Cable out...
  • Page 11 Mounting the POS onto a Table To avoid the POS from backward tilting and wagging when a user touches the LCD panel, use the desktop-mounting kit shipped with the POS to hold and secure the POS firmly on a table. Please follow the steps below to mount the POS.

  • Page 12: Loading A Paper Roll

    Loading a Paper Roll Press 1. Press down the paper roll cover release lever to release the paper roll cover. 2. The paper roll cover ejects. Then, open the paper roll cover manually. 3. Drop the 3-inch wide thermal paper roll inside the paper roll compartment of the printer, as shown in the right figure.
  • Page 13 6. Determine that the paper roll is completely loaded in the paper roll compartment of the printer and the paper roll is dragged out of the track between the paper roll cover and the front cover. Powering ON/OFF the HS-2210E Power ON the HS-2210E Then press the power button to power on the POS.

  • Page 14: Status Led Indicator

    Status LED Indicator After supplying power to the HS-2210E, powering ON the desktop POS, you can read the system operation status from the LED indicators on the system. The LED status is described below. Status Description Solid orange System standby POWER LED Solid blue System ON...
  • Page 15 Setting up the HS-2210E Printer There are two different ways to set up the HS-2210E series printer. The first way of setup is implemented through the hardware DIP switch installed in the HS-2210E series printer for setting up functions such as baud rate, paper width and others.
  • Page 16 ON OFF OFF OFF OFF Setup through software switch: The HS-2210E series end users are allowed to set up the HS-2210E series printer through the software switch setting, which means that software utility must be used for setup of other functions. Please visit our web site to download the HS-2210E http://www.posiflex.com/up/Download/downlaod...

  • Page 17: Specifications

    Specifications HS-2210E Dual Core ARM Cortex-A7 - 1.0G CPU Memory DDR3, 1GB Android 4.2.2 Display 9.7" 1024 x 768 LVDS LCD Panel HDMI Display (reserved for second display) NAND Flash MLC NAND flash, 8GB DB9 port x 2, 1 Port on bottom-side I/O plate (support 4bit) Serial Port and 1 port on the top-side I/O plate (support 4bit) CR Port...
  • Page 18 0°C - 50°C, 20%RH - 90%RH Storage Condition -20°C - 70°C, 10%RH - 90%RH The product information and specifications are subject to change without prior notice. To get the detailed information on HS-2210E, please check this model from Posiflex Global Website (http://www.posiflex.com/en-global/Download/download).
  • Page 19 <MEMO>...
  • Page 20 <MEMO>...
