HT - 2212 Pro Series
User's Manual
Rev. Original
FCC Notes:
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance
with the instructions manual, may cause interference to radio
communications. It has been tested and found to comply with
limits for a Class A digital device pursuant to subpart J of Part 15 of FCC Rules, which
are designed to provide reasonable protection against interference when operated in a
commercial environment. Operation of this equipment in a residential area is like ly to
cause interference in which case the user at his own expense will be required to take
whatever measures to correct the interference.
Warranty Limits:
Warranty terminates automatically when any person other than the authorized
technicians opens the machine. The user should consult his/her dealer for the problem
happened. Warranty voids if the user does not follow the instructions in application of
this merchandise. The manufacturer is by no means responsible for any damage or
hazard caused by improper application.
About This Manual:
Posiflex has made every effort for the accuracy of the content in this manual. However,
Posiflex will assume no liability for any technical inaccuracies or editorial or other
errors or omissions contained herein, nor for direct, indirect, incidental, consequential
or otherwise damages, including without limitation loss of data or profits, resulting
from the furnishing, performance, or use of this material.
This information is provided "as is" and Posiflex Inc. expressly discl a ims any
warranties, expressed, implied or statutory, including without limitation implied
warranties of merchantability or fitness for particular purpose, good title and against
infringement.
The information in this manual contains only essential hardware concerns for general
user and is subject to change without notice. Posiflex reserves the right to alter product
designs, layouts or drivers without notification. The system integrator shall provide
applicative notices and arrangement for special options utilizing this product. The user
may find the most up to date information of the hardware from web sites:
http://www.posiflex.com or http://www.posiflex.com.tw
All data should be backed-up prior to the installation of any drive unit or storage
peripheral. Posiflex will not be responsible for any loss of data resulting from the use,
disuse or misuse of this or any other Posiflex product.
All rights are strictly reserved. No p art of this documentation may be reproduced,
stored in a retrieval system, or transmitted in any form or by any means, electronic,
mechanical, photocopying, or otherwise, without prior express written consent from
Posiflex Inc. the publisher of this documentation.
© Copyright Posiflex Inc. 2006
All brand and product names and trademarks are the property of their respective holders.
Part 1
P/N: 15430900010

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HT-2212 Pro Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for POSIFLEX HT-2212 Pro Series

  • Page 1 HT - 2212 Pro Series User’s Manual Rev. Original FCC Notes: This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions manual, may cause interference to radio communications. It has been tested and found to comply with limits for a Class A digital device pursuant to subpart J of Part 15 of FCC Rules, which are designed to provide reasonable protection against interference when operated in a commercial environment.
  • Page 2 ALERT TO OUR HONORABLE CUSTOMERS: l Please always read thoroughly all the instructions and documents delivered with the product before you do anything about it. Don’t take any premature action before you have a full understanding of the consequences. l This product contains inside a Lithium battery and maybe also a sealed type Lead acid battery if the UPS battery option is ordered.
  • Page 3: Brief Introduction

    THE USER’S MANUAL The purpose of this manual is to guide the user in the initial installation and general use of the Posiflex POS terminals HT-2212 Pro series. It does not explain any application software that may be supplied with it.
  • Page 4: The Optional Items

    VGA Port: There is a VGA connector for connection of external monitor with + 12 V DC power support capability after jumper setting change. USB Ports: The HT-2212 Pro series is equipped with 6 USB type A connectors for connection of USB (Universal Serial Bus) devices. One of the 6 ports is extended to one top edge of case for easy connection to the integrated upgrade kit BC-300 or SD-300.
  • Page 5: System Box Contents

    UPS Battery: 2.3 AH 12V lead acid maintenance free battery 2-in-1 Cash Drawer Control Cable: Cable CCBLA-238, when added to the CR port of the HT-2212 Pro series, can be used to control two Posiflex printer drive type cash drawers.
  • Page 6: Installation Guides

    TECHNICAL ENHANCEMENTS Applicable technical enhancements in HT-2212 Pro series include serial COM port power supply settings, RTC battery replacement, VGA port power supply setting, DRAM upgrades and adding a half-length PCI adapter card.
  • Page 7: Power Adaptor

    of the system unit before pressing these 2 springs. The LCD and touch panel may flip forward by gravity and get or cause damage by hitting anything in front of the system unit. POWER ADAPTOR The power connector resides in the lower left corner of main connector area.
  • Page 8: Lcd Cashier Display

    LCD CASHIER DISPLAY Push down the round plastic Push inward to button at rear of the display base as turn left-right circled in right picture to adjust the display up and down. Release the Push down to button when done will lock the panel turn up-down firmly for application.
  • Page 9: Barcode Scanner (Option)

    PROGRAMMABLE KEYBOARD & KEYPAD (OPTION) All types of Posiflex programmable keyboards can be applied in HT system. Most recommended keyboard models are: KB-6000, KB-6200 series and KB-6600. Just connect it to the PS/2 KB port in the main connection area. The application of the keyboard and the keypad KP-200 requires no software driver and is free from any software compatibility issue.
  • Page 10: Operating System Recovery

    control of the COM1 serial port. Use the cable supplied with the Posiflex cash drawer (Part No. 21863018010) for connection to the CR port in HT system. This cable has a 6- pole plug at one end and an 8-pole plug at the other. The 8-pole plug should be inserted into the connector marked: “signal cable from POS Printer”...
  • Page 11: Operating System Installation

    OPERATING SYSTEM INSTALLATION This product is highly professionalized equipment. The installation of an OS into a machine without any preloaded OS could constitute major difficulty for average user who either has barely limited technical knowledge of this professionalized equipment or is insufficiently equipped with necessary facilities to accomplish such a task.
  • Page 12 (3 ~ 20 min. depending on loading and battery condition) power failure. Battery replacement: In the preloaded OS for a HT-2212 Pro series, there is a built in utility Posiflex Power Switch Manager that will indicate the UPS battery status of the battery. When an installed...
  • Page 13: Led Indicators

    replace the used up UPS battery at power off as soon as possible. Emergency treatment: The battery is constructed maintenance free and leakproof. Its storage space in HT system also provides very good protection as long as the ambient temperature remains below 30 C and the ventilation of the HT system remains free.
  • Page 14: Power On/Off Control

    usage of the battery power, the flashing LED will keep on flashing for few seconds before steady till the AC supply is stable. POWER ON/OFF CONTROL The HT terminal implements electronic power control, such that the main power to the system may be controlled by many methods as below: 1.
  • Page 15 Emergency Power Off In case of serious system halt due to any reason, the system could fail to be powered off through normal means. Press and hold the Power ON/OFF Switch for Emergency Power Off. Release the switch after the system powered off.
  • Page 16: Customer Display

    drag and drop feature. If the point is touched, released and touched within a short time interval, it will simulate double-clicking left button of the mouse. Emulating the click on right button of a real mouse is further illustrated in paragraph below.
  • Page 17: Fan Control

    For bar code card reading, it is still required to insert the card to the bottom with bar code stripe facing the mark aside the slot. For smart card reading, please insert the end of the smart chip first and have the chip facing the mark aside the side slot of KP-200 as in the right picture.
  • Page 18 VENTILATION MAINTENANCE To keep this equipment in orderly service, following maintenance should be performed on a regular basis. Removing Front Cover Please first remove Front Cover power signal connection this Release Opening equipment. Please then check at the bottom side of Chassis Bottom View the chassis that there is a gap between the bottom side of front cover and the chassis at the left corner of...
  • Page 19 Cleaning for Front Ventilation Use vacuum cleaner to remove any dust or threads accumulation away from both the ventilation holes on front cover and ventilation grids on chassis exposed after removal of the front cover. Front Ventilation Grids on Chassis Ventilation Holes on Front Cover Replacing Front Cover Follow the opposite procedure as removing the front cover to replace...
  • Page 20 Cleaning for Side Ventilation Use vacuum cleaner to remove any dust or threads accumulation away from outsides of both ventilation grids on chassis exposed after removal of the front cover as in pictures below and close back the top cover when done. Side Ventilation Grids on...
