Using the Demo Image
Running the Demo Applications
Running the TV-Out Application
The TV Out application has two output formats: PAL and NTSC. You will need a special
cable.
To use the TV-Out application, follow these steps:
1. Plug the RCA Video/Audio cable jack to the J19 Video/Audio jack on the Personality
board.
2. Connect the RCA end to the TV.
3. Before running the application, you must disable the power-saving features of the
Windows Embedded CE 6.0 image, because the TV Out signal will be dropped if the
power-saving state starts. To disable the backlight savings, tap and hold the stylus for
one or two seconds at the center of the Windows Embedded CE 6.0 desktop.
34
i.MX27 PDK 1.0 Quick Start Guide, Rev. 1.0
