Applications
Guide
Engineered Smoke
Control System
™
for TRACER SUMMIT
BAS-APG001-EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Engineered Smoke Control System and is the answer not in the manual?

Questions and answers

Related Manuals for Trane Engineered Smoke Control System

Summary of Contents for Trane Engineered Smoke Control System

  • Page 1 Applications Guide Engineered Smoke Control System ™ for TRACER SUMMIT BAS-APG001-EN...
  • Page 3 Applications Guide Engineered Smoke Control System ™ for TRACER SUMMIT BAS-APG001-EN September 2006...
  • Page 4 Although Trane has tested the hardware and software described in this guide, no guarantee is offered that the hardware and software are error free. Trane reserves the right to revise this publication at any time and to make changes to its content without obligation to notify any per- son of such revision or change.
  • Page 5 NOTICE: Warnings and Cautions appear at appropriate sections throughout this manual. Read these carefully: WARNING Indicates a potentially hazardous situation, which, if not avoided, could result in death or serious injury. CAUTION Indicates a potentially hazardous situation, which, if not avoided, may result in minor or moderate injury. It may also be used to alert against unsafe practices.

  • Page 7: Table Of Contents

    Contents Contents Chapter 1 Smoke control overview ..... 1 Methods of smoke control ........2 Compartmentation method.
  • Page 8 Contents Smoke control system equipment ......23 Equipment supervision ........26 System testing .
  • Page 9 Contents Circuit requirements ........59 Wiring high-voltage power .
  • Page 10 Contents Binary outputs......... . . 94 Analog outputs (UUKL nondedicated only) .
  • Page 11 Contents Node ..........131 Binding types .
  • Page 12 Contents BAS-APG001-EN...

  • Page 13: Chapter 1 Smoke Control Overview

    Chapter 1 Smoke control overview Smoke is one of the major problems created by a fire. Smoke threatens life and property, both in the immediate location of the fire and in locations remote from the fire. The objectives of smoke control include: •...

  • Page 14: Methods Of Smoke Control

    Chapter 1 Smoke control overview Methods of smoke control Smoke control system designers use five methods to manage smoke. They use the methods individually or in combination. The specific methods used determine the standards of design analysis, performance criteria, acceptance tests, and routine tests. The methods of smoke control consist of: compartmentation, dilution, pressurization, air flow, and buoyancy.
  • Page 15 Methods of smoke control Figure 1: Sample pressure difference across a barrier Table 1 provides the National Fire Protection Association (NFPA) recommended minimum pressure difference between the high-pressure side and the low-pressure side. Table 1: Recommended minimum pressure difference Minimum pressure Ceiling height difference Building type...

  • Page 16: Airflow Method

    Chapter 1 Smoke control overview Table 2: Maximum allowable pressure differences across doors Door width (in. [m]) 32 (0.813) 36 (0.914) 40 (1.02) 44 (1.12) 46 (1.17) Door closer force Pressure difference (lb. [N]) (In.w.c. [Pa]) 6 (26.7) 0.45 (112.0) 0.40 (99.5) 0.37 (92.1) 0.34 (84.6)

  • Page 17: Buoyancy Method

    Applications of smoke control methods A disadvantage of the airflow method is that it supplies increased oxygen to a fire. Within buildings, the airflow method must be used with great caution. The airflow required to control a wastebasket fire has sufficient oxygen to support a fire 70 times larger than the wastebasket fire.
  • Page 18 Chapter 1 Smoke control overview Zoned smoke control cannot limit the spread of smoke within the smoke control zone. Consequently, occupants of the smoke control zone must evacuate as soon as possible after fire detection. Figure 3: Sample arrangements of smoke control zones + : Represents high-pressure zone –...

  • Page 19: Stairwell Smoke Control

    Applications of smoke control methods Figure 4: Sample HVAC operation during smoke control Note: For simplicity, Figure 4 does not show the ducts on each floor or the penthouse equipment. When an HVAC system serves only one smoke control zone, the following sequence provides smoke control: 1.
  • Page 20 Chapter 1 Smoke control overview If the technique employs modulated supply airflow, a fan provides at least minimum pressure when all stairwell access doors are open. Either a single-speed fan with modulating bypass dampers or a variable frequency drive varies the flow of air into the stairwell to compensate for pressure changes.

  • Page 21: Elevator Shaft Smoke Control

    Applications of smoke control methods Single and multiple injection pressurization techniques The single injection and multiple injection techniques provide pressurization air to a stairwell (Figure 6). Both techniques use one or more pressurization fans located at ground level, roof level, or any location in between.

  • Page 22: Atrium Smoke Control

    Chapter 1 Smoke control overview more information about elevator shaft smoke control, refer to Klote, J.K., and Milke, J.A. (Design of Smoke Management Systems, 1992). Atrium smoke control Atrium smoke control uses buoyancy to manage smoke in large-volume spaces with high ceilings. The buoyancy of hot smoke causes a plume of smoke to rise and form a smoke layer under the atrium ceiling.
  • Page 23 Applications of smoke control methods Natural smoke venting technique The natural smoke venting technique employs vents in the atrium ceiling or high on the atrium walls to let smoke flow out without the aid of fans (Figure 8). The applicability of natural venting depends primarily on the size of the atrium, the outside temperature, and the wind conditions.

  • Page 24: Underground Building Smoke Control

    Chapter 1 Smoke control overview Underground building smoke control The smoke control objective for underground buildings is to contain and remove smoke from the alarm zone. The smoke control system fully exhausts the alarm zone and provides makeup air to replace the exhausted air.

  • Page 25: Zoned Smoke Control Detection And Activation

    Smoke detection and system activation Zoned smoke control detection and activation Zoned smoke control activation occurs on a signal from either a sprinkler water flow switch or a heat detector. For maximum benefit, the zoned smoke control system should only respond to the first alarm. Two design techniques that prevent detection of smoke in zones other than the first zone reporting are: •...
  • Page 26 Chapter 1 Smoke control overview Note: Atrium smoke control should not activate on signals from sprinkler water flow switches or heat detectors. Since the temperature of a smoke plume decreases with height, activation by these devices may not provide reliable results. Beam smoke detectors minimize interference problems created by stratified hot air under atrium ceilings.

  • Page 27: Design Approaches To Smoke Control

    Design approaches to smoke control Design approaches to smoke control Smoke control methods provide a mechanical means of directing smoke movement in an enclosed space. The application of one or more methods to a building provides a building smoke control system. Design approaches to smoke control include the no smoke, tenability, and dedicated system approaches.

  • Page 28: Design Considerations For Smoke Control

    Chapter 1 Smoke control overview Design considerations for smoke control Two occurrences will hinder smoke control: Plugholing • • Smoke feedback Smoke control systems should be designed to address the problems that are caused by plugholing and smoke feedback. Plugholing Plugholing occurs when an exhaust fan pulls fresh air into the smoke exhaust (Figure 10).

  • Page 29: Smoke Feedback

    Design considerations for smoke control Smoke feedback Smoke feedback occurs when smoke enters a pressurization fan intake and flows into protected spaces. Design techniques reduce the probability of smoke feedback: Supply air intakes located below openings from which smoke might •...
  • Page 30 Chapter 1 Smoke control overview BAS-APG001-EN...

  • Page 31: Chapter 2 Pre-Installation Considerations

    Chapter 2 Pre-installation considerations This chapter provides considerations that must be given prior to installing an engineered smoke control system. The pre-installation considerations are: • Zone operating modes • Associated equipment Equipment supervision • System testing • Alarm response •...

  • Page 32: Normal Mode

    Chapter 2 Pre-installation considerations Normal mode A zone is in normal mode when no fire, smoke, or sprinkler alarms are present in the building. In some zoning systems, a zone may be in normal mode if an alarm condition is present in the building but the zone is not affected.
  • Page 33 Note: Fire alarm system equipment is neither furnished nor installed by Trane. Area smoke detectors Area smoke detectors detect the presence of smoke at the ceiling. When activated, an area smoke detector signals the fire alarm system. The zoning of area smoke detectors must reflect the zoning of the building.

  • Page 34: Fire Alarm Control Panel

    Chapter 2 Pre-installation considerations system, since a pull station is not necessarily activated in the zone that contains the smoke or fire. Sprinkler flow devices Fire alarm system equipment may include two types of sprinkler flow devices: sprinkler flow switches and tamper switches. Sprinkler flow switches, installed in fire sprinkler lines, notify the fire alarm control panel (FACP) of flow in the sprinkler lines.

  • Page 35: Smoke Control System Equipment

    Associated equipment Lights The FSCS provides lights that show the mode of each zone and the status of each piece of smoke control mechanical equipment. The status lights must conform to a specific color code scheme (Table 3). Table 3. Pilot lamp color codes Color Description Green...
  • Page 36 Chapter 2 Pre-installation considerations The smoke control system controls fans and positions dedicated and nondedicated dampers, both in the smoke control zones and at the air- handling systems. It may also position dampers or air modulation devices such as variable-air-volume (VAV) boxes serving the smoke control zones. Equipment associated with the smoke control system includes: dampers, fans, verification of operation equipment, and the Tracer™...
  • Page 37 Associated equipment Smoke dampers are ordered as a complete assembly. They are typically two-position dampers and have end switches that indicate the fully open and fully closed position. The switches are installed in the field. Dampers actuate with two types of control: pneumatic actuation and electrical actuation.

  • Page 38: Equipment Supervision

    Chapter 2 Pre-installation considerations and dampers: status switches, differential pressure switches, airflow paddle switches, current-sensing relays, limit switches, and end switches. Status switches at fans and dampers monitor the operation of the devices. Multiple binary inputs at the Tracer MP581s verify the On and Off status of fans and the Open and Closed status of dampers.

  • Page 39: System Testing

    System testing System testing System testing is a pre-installation consideration. To verify proper operation, the smoke control system must include provisions for: automatic weekly self-testing and manual periodic testing. Automatic weekly self-testing As UL requires, the smoke control system provides automated weekly self-tests for dedicated smoke control system components.
  • Page 40 Chapter 2 Pre-installation considerations Table 5. Sample automatic smoke control matrix (dedicated) First smoke zone in alarm Equipment Zone 1 Zone 2 Zone 3 Zone 4 Main sup fan Main R/E fan Stair press fan 1st flr sup dmpr Close Open Close Close...

  • Page 41: Response Times

    Response times Response times Response times are a pre-installation consideration. For a discussion of response time requirements for smoke control systems, refer to NFPA 92A (NFPA 2000, Recommended Practice for Smoke Control Systems), section 3.4.3.3 and NFPA 92B (NFPA 2000, Guide for Smoke Management Systems in Malls, Atria, and Large Areas), section 4.4.4.
  • Page 42 Table 8. Cabling practices and restraints Maximum distance Type Monitored data paths Refer to the best wiring practices Trane LonTalk communication link given in BMTX-SVN01A-EN for installing Lontalk communication links. Refer to the wiring requirements Tracer MP580/581 EX2 I/O bus com-...

  • Page 43: Chapter 3 Installation Diagrams

    Chapter 3 Installation diagrams Smoke control system overview An engineered smoke control system can be added on to a Tracer ™ Summit building automation system. The system layout, wiring requirements, and capacities for smoke control applications differ from Tracer Summit systems that do not employ smoke control.

  • Page 44: System Riser Diagrams

    Chapter 3 Installation diagrams System riser diagrams System riser diagrams (Figure 11) show panel locations, power requirements, power sources, and interconnecting wiring requirements. They also show the wiring that must be in conduit. Figure 11. Sample system riser diagram BAS-APG001-EN...

  • Page 45: System Termination Diagrams

    An example of an expected operation description is closed contact opens damper. • Diagrams for field devices not furnished by Trane are created during installation. After installation, the diagrams become part of the as- built documentation. Diagrams for the control of starters and variable flow devices (VFDs) •...

  • Page 46: Tracer Mp581 To Fscs Wiring

    Chapter 3 Installation diagrams Tracer MP581 to FSCS wiring The FSCS panel is designed for a specific smoke control system (Figure 13). The FSCS panel comes from a listed vendor and is provided as part of the smoke control system. Before ordering the panel, UL must approve front panel drawings that show lights and switches.
  • Page 47 System termination diagrams The wiring between a Tracer MP581 and the FSCS is non-supervised and power limited. Additional requirements are: • Tracer MP581 and FSCS must be in the same room. • Wiring between the Tracer MP581 and FSCS must be in conduit. Wiring distance cannot exceed 20 ft.
  • Page 48 Chapter 3 Installation diagrams Figure 14. Tracer MP581 to FSCS wiring BAS-APG001-EN...

  • Page 49: Tracer Mp581 To Facp Wiring

    System termination diagrams Tracer MP581 to FACP wiring The wiring between the Tracer MP581 and the FACP is non-supervised and power limited. In addition: Tracer MP581 and FACP must be in the same room. • Wiring between the Tracer MP581 and FACP must be in conduit. •...
  • Page 50 Chapter 3 Installation diagrams Figure 15. Tracer MP581 to FACP wiring BAS-APG001-EN...

  • Page 51: Chapter 4 Installing The Tracer Summit Bmtx Bcu

    Make sure that the selected location meets the operating environment requirements described in this section and clearance requirements described in this Figure 16 on page 40. The BCU must be installed indoors. Trane recommends locating it: • Near the controlled equipment to reduce wiring costs •...

  • Page 52: Clearances

    Chapter 4 Installing the Tracer Summit BMTX BCU Clearances Make sure that the mounting location has enough room to meet the mini- mum clearances shown in Figure 16. Figure 16. Minimum clearances for the BMTX BCU enclosure 12 in. (30 cm) 12 in.
  • Page 53 Mounting the hardware Figure 17. BMTX BCU enclosure dimensions Top view Front view Left view Right view Bottom view Note: Six of the twelve knockouts are dual- sized knockouts for 1-inch (25 mm) and 0.75-inch (19 mm) conduit. BAS-APG001-EN...

  • Page 54: Mounting The Back Of The Enclosure

    Chapter 4 Installing the Tracer Summit BMTX BCU Mounting the back of the enclosure The back of the enclosure is shipped with the termination board installed inside it. IMPORTANT The termination board should be shipped with the grounding screw installed. Verify this by checking the location shown in Figure 18. The enclosure door is shipped separately.

  • Page 55: Wiring High-Voltage Ac Power

    Wiring high-voltage ac power 2. Set the enclosure back aside and drill holes for the screws at the marked locations. Drill holes for #10 (5 mm) screws or #10 wall anchors. Use wall anchors if the mounting surface is dry wall or masonry. 3.
  • Page 56 Chapter 4 Installing the Tracer Summit BMTX BCU CAUTION Use copper conductors only! Unit terminals are designed to accept copper conductors only. Other conductors may cause equipment damage. 1. Lock open the supply-power disconnect switch. 2. At the top-right corner of the enclosure, remove the knockout for ½ in (13 mm) conduit.
  • Page 57 Wiring high-voltage ac power Figure 19. AC wiring BAS-APG001-EN...

  • Page 58: Emi/Rfi Considerations

    Chapter 4 Installing the Tracer Summit BMTX BCU EMI/RFI considerations Take care to isolate HVAC controllers from electromagnetic interference (EMI) and radio frequency interference (RFI). Such interference can be caused by radio and TV towers, hospital diagnostic equipment, radar equipment, electric power transmission equipment, and so on. In addi- tion, take care to prevent the BMTX BCU from radiating EMI and/or RFI.
  • Page 59 EMI/RFI considerations Figure 20. Checking the earth ground BAS-APG001-EN...

  • Page 60: Connecting The Main Circuit Board

    Chapter 4 Installing the Tracer Summit BMTX BCU Connecting the main circuit board The main circuit board is attached to a plastic frame. It is shipped separately. The board can be kept in the office and programmed while the back of the enclosure is mounted and the termination board, which is attached to the back of the enclosure, is wired.
  • Page 61 Connecting the main circuit board Figure 22. Connecting the frames 3. Connect the 24 Vac power cable to the termination board. The seven- segment LED display should light up. 4. Connect the Ethernet cable to the Ethernet connector on the circuit board (this step applies to UUKL nondedicated systems only).

  • Page 62: Installing The Door

    Chapter 4 Installing the Tracer Summit BMTX BCU Installing the door To install the enclosure door: 1. Unpack the door and check for missing or damaged parts. Check to make sure that the magnetic latches are installed. Check for any cracks in the plastic. 2.

  • Page 63: Transtector, Ethernet (Uukl Nondedicated Only), And Lontalk Connections On The Bmtx Bcu

    Transtector, Ethernet (UUKL nondedicated only), and LonTalk connections on the BMTX BCU Transtector, Ethernet (UUKL nondedicated only), and LonTalk connections on the BMTX BCU To comply with UUKL, a protection device must be wired to the BMTX BCU to reduce transients in the ac power. Figure 24 describes connecting an ac power transient protection device to a BMTX BCU.
  • Page 64 Chapter 4 Installing the Tracer Summit BMTX BCU Figure 25 shows the Ethernet LAN connection (UUKL nondedicated only) and the LonTalk connection to the BMTX BCU. Figure 25. Ethernet (UUKL nondedicated only) and LonTalk connection locations on the BMTX BCU LonTalk connections Ethernet connection Note:...

  • Page 65: Controller

    Chapter 5 Installing the Tracer MP581 programmable controller Installation guidelines Guidelines for installing a Tracer MP581 include: A Tracer MP581 that monitors the fire alarm control panel for • consistency (FACP) must be installed in the same room as the FACP. It must be installed within 20 feet of the FACP.

  • Page 66: Specifications

    Chapter 5 Installing the Tracer MP581 programmable controller Specifications The Tracer MP581 conforms to the specifications shown in Table 13. Table 13. Tracer MP581 specifications Weight 15 lb (7 kg) Operating temperature From –40°F to 120°F (–40°C to 49°C) Storage temperature From –58°F to 203°F (–50°C to 95°C) Humidity 10–90% non-condensing...

  • Page 67: Selecting A Mounting Location

    Make sure that the location meets the operating environment require- ments and clearance requirements described in the following sections. The Tracer MP581 controller must be installed indoors. Trane recom- mends locating the Tracer MP581 controller in the same room (within 20 ft) of the controlled equipment to reduce wiring costs.

  • Page 68: Clearances And Dimensions

    Chapter 5 Installing the Tracer MP581 programmable controller Clearances and dimensions Make sure that the mounting location has enough room to meet the mini- mum clearances shown in Figure 26. Figure 27 on page 57 shows the dimensions of the Tracer MP581 enclosure. Figure 26.
  • Page 69 Selecting a mounting location Figure 27. Tracer MP581 enclosure dimensions Top view Front view Left view Right view Bottom view Note: Six of the twelve knockouts are dual-sized knockouts for 1-inch (25 mm) and 0.75-inch (19 mm) conduit. BAS-APG001-EN...

  • Page 70: Mounting The Back Of The Enclosure

    Chapter 5 Installing the Tracer MP581 programmable controller Mounting the back of the enclosure The back of the enclosure is shipped with the termination board installed inside it. IMPORTANT The termination board should be shipped with the grounding screw installed. Verify this by checking the location shown in Figure 28. The enclosure door is shipped separately.

  • Page 71: Wiring High-Voltage Ac Power

    Wiring high-voltage ac power 2. Set the enclosure aside and drill holes for the screws at the marked locations. Drill holes for #10 (5 mm) screws or #10 wall anchors. Use wall anchors if the mounting surface is dry wall or masonry. 3.

  • Page 72: Wiring High-Voltage Power

    Chapter 5 Installing the Tracer MP581 programmable controller Wiring high-voltage power WARNING Hazardous voltage! Before making electrical connections, lock open the supply-power dis- connect switch. Failure to do so could result in death or serious injury. CAUTION Use copper conductors only! Unit terminals are designed to accept copper conductors only.
  • Page 73 Wiring high-voltage ac power Figure 30. Terminal block for high-voltage power wires WARNING Hazardous voltage! The cover plate must be in place when the controller is operating. Fail- ure to replace the cover plate could result in death or serious injury. 10.

  • Page 74: Emi/Rfi Considerations

    Chapter 5 Installing the Tracer MP581 programmable controller EMI/RFI considerations Take care to isolate HVAC controllers from electromagnetic interference (EMI) and radio frequency interference (RFI). Such interference can be caused by radio and TV towers, hospital diagnostic equipment, radar equipment, electric power transmission equipment, and so on. In addi- tion, take care to prevent the Tracer MP581 controller from radiating EMI and/or RFI.
  • Page 75 EMI/RFI considerations Figure 31. Checking the earth ground BAS-APG001-EN...

  • Page 76: Wiring Inputs And Outputs

    Chapter 5 Installing the Tracer MP581 programmable controller Wiring inputs and outputs The Tracer MP581 enclosure is designed to simplify the wiring and con- figuration of inputs and outputs by providing a large space for routing wires and by eliminating the need to manipulate jumpers. Table 16 lists Tracer MP581 inputs and outputs.

  • Page 77: Wire Routing

    Wiring inputs and outputs Wire routing Figure 32 shows how to route input/output wires through the enclosure. It also shows the locations of wire-tie brackets. See Figure 27 on page 57 for knockout locations and dimensions. Metal conduit may be required by local codes when running input/output wires.

  • Page 78: Screw Terminal Locations

    Chapter 5 Installing the Tracer MP581 programmable controller Screw terminal locations Figure 33 shows screw terminal locations on the termination board. The top row of screw terminals is for signal wires, and the bottom row of screw terminals is for common wires. To make sure that the wires lie flat, use the wire strip guide on the termination board to strip input/output wires to the correct length.

  • Page 79: Wiring Universal Inputs

    Wiring inputs and outputs Wiring universal inputs The Tracer MP581 controller has 12 universal inputs. Use the Rover ser- vice tool to configure inputs for analog or binary operation. The common terminals on the Tracer MP581 termination board are con- nected to the metal enclosure by means of a ground screw.

  • Page 80: Wiring Analog Outputs

    Chapter 5 Installing the Tracer MP581 programmable controller Wiring analog outputs The Tracer MP581 controller has six analog outputs. These outputs can be either 0–10 Vdc outputs or 0–20 mA outputs. Analog outputs control actuators and secondary controllers. To wire an analog output: 1.

  • Page 81: Wiring Binary Outputs

    Wiring inputs and outputs Wiring binary outputs The Tracer MP581 controller has six binary outputs. These are powered outputs, not dry-contact outputs. IMPORTANT Use pilot relays for dry-contact outputs when the load is greater than 6 VA or has a current draw of greater than 0.25 A. Use powered outputs when the load is less than 6 VA or has a current draw of less than 0.25 A.

  • Page 82: Checking Binary Inputs

    Chapter 5 Installing the Tracer MP581 programmable controller Figure 36. Wiring binary outputs Powered output < 1000 ft Signal (300 m) Common Pilot relay Tape back shield 24 Vac coil Signal < 1000 ft (300 m) Common NOTE: To reduce the potential for transients, locate output devices in the same room with the Tracer MP581.

  • Page 83: Checking Outputs

    Checking outputs Checking outputs Follow the procedures in this section to test outputs for proper operation. IMPORTANT Perform the tests in this section before providing power to the termina- tion board or installing the main circuit board. Failure to do so will result in incorrect multi-meter readings.

  • Page 84: Checking 0-20 Ma Analog Outputs

    Chapter 5 Installing the Tracer MP581 programmable controller 1. Make sure that the actuator is connected but powered off. 2. Set the multi-meter to measure Vac, then measure the voltage across the analog output at the signal and common screw terminals. The measured voltage should be less than 0.1 Vac.
  • Page 85 Checking outputs 3. Set the multi-meter to measure Vdc, then measure the voltage across the analog output at the signal and common screw terminals. The measured voltage should be less than 0.1 Vdc. If the voltage is greater than this, a shared power supply may be incorrectly con- nected.

  • Page 86: Wiring Lontalk To The Tracer Mp581

    Chapter 5 Installing the Tracer MP581 programmable controller Wiring LonTalk to the Tracer MP581 IMPORTANT When installing the Tracer MP581 controller in areas of high electro- magnetic interference (EMI) and radio frequency interference (RFI), fol- low the additional installation instructions in “EMI/RFI considerations” on page 62.
  • Page 87 Wiring LonTalk to the Tracer MP581 3. At the last controller on the LonTalk link: • Connect the white wire to the first LonTalk screw terminal. Connect the black wire to the second LonTalk screw terminal. • Place a 105 Ω termination resistor across the LonTalk screw •...

  • Page 88: Installing The Circuit Board

    Chapter 5 Installing the Tracer MP581 programmable controller Installing the circuit board The main circuit board is not installed in the Tracer MP581 enclosure when it ships. You can store the circuit board in the office while the enclo- sure is mounted and wired. After wiring has been completed, connect the circuit board to the termination board.
  • Page 89 Installing the circuit board 5. Align the snaps on the top frame with the mounting locks on the bot- tom frame, as shown in Figure 40, then push the two frames together. You will hear a click when the frames connect. Figure 40.
  • Page 90 Chapter 5 Installing the Tracer MP581 programmable controller Figure 41. 24 Vac power-supply cable connection 24 Vac power connector BAS-APG001-EN...

  • Page 91: Verifying Operation And Communication Of The Tracer Mp581

    Verifying operation and communication of the Tracer MP581 Verifying operation and communication of the Tracer MP581 This chapter describes the location and function of the Service Pin button and the light-emitting diodes (LEDs) on the Tracer MP581 controller. Service Pin button The Service Pin button is located on the main circuit board as shown in Figure 42.

  • Page 92: Binary Output Leds

    Chapter 5 Installing the Tracer MP581 programmable controller Binary output LEDs The BO1–BO6 LEDs indicate the status of the six binary outputs. Table 18 describes binary output LED activity. Note: Each binary output LED reflects the status of the output relay on the circuit board.

  • Page 93: Status Led

    Verifying operation and communication of the Tracer MP581 Status LED The green Status LED indicates whether the controller has power applied to it. Table 20 describes Status LED activity. Table 20. Green Status LED LED activity Explanation LED is on continuously Power is on (normal operation).

  • Page 94: Installing The Door

    Chapter 5 Installing the Tracer MP581 programmable controller Installing the door To install the enclosure door: 1. Unpack the door and check for missing or damaged parts. Check to make sure that the magnetic latches and touch screen (if ordered) are installed. Check for any cracks in the plastic. 2.
  • Page 95 Installing the door 2. For doors with an operator display, disconnect the operator-display cable from operator display. 3. Lift the door to pull the hinges from the hinge holes. BAS-APG001-EN...
  • Page 96 Chapter 5 Installing the Tracer MP581 programmable controller BAS-APG001-EN...

  • Page 97: Chapter 6 Installing The Ex2 Expansion Module

    Chapter 6 Installing the EX2 expansion module The EX2 is a field-installed expansion module for the Tracer MP581 pro- grammable controller. Up to four EX2s with metal enclosure, model num- ber 4950 0523, can be connected to a Tracer MP581. Each EX2 adds the following inputs and outputs to a Tracer MP581: Six universal inputs •...

  • Page 98: Storage Environment

    Temperature: From –40°F to 185°F (–40°C to 85°C) • Relative humidity: 5–93%, non-condensing • Mounting location Trane recommends locating the EX2 module: In an environment protected from the elements • • Where public access is restricted to minimize the possibility of tam- pering or vandalism •...

  • Page 99: Terminal Strips

    Terminal strips Terminal strips The EX2 module is shipped with terminal strips already in place (Figure 45). If you need to replace the circuit board, you can transfer the terminal strips to the new board without rewiring. Figure 45. Terminal strip locations Binary outputs terminal strip Universal inputs...

  • Page 100: Ac-Power Wiring

    Chapter 6 Installing the EX2 expansion module Figure 46. Mounting the metal-enclosure EX2 AC-power wiring Use 16 AWG copper wire for ac-power wiring. All wiring must comply with National Electrical Code and local codes. Use a UL-listed Class 2 power transformer supplying a nominal 24 Vac. The transformer must be sized to provide adequate power to the EX2 module (10 VA) and outputs (a maximum of 6 VA per binary output).

  • Page 101: Wiring Ac-Power To The Metal-Enclosure Module

    AC-power wiring CAUTION Equipment damage! Complete input/output wiring before applying power to the EX2 mod- ule. Failure to do so may cause damage to the module or power trans- former due to inadvertent connections to power circuits. CAUTION Equipment damage! To prevent module damage, do not share 24 Vac between modules.
  • Page 102 Chapter 6 Installing the EX2 expansion module Figure 47. Power and ground terminals Note: If a power transformer must be shared between EX-2 modules (an example would be at the FSCS), the +VA rating on output is 0.6 VA. This is enough to run any LED or sonalent provided on the FSCS.

  • Page 103: I/O Bus Wiring

    Existing sites that have already been wired with low- capacitance, 18-gauge, shielded, twisted pair with stranded, tinned- copper conductors (Trane-approved, purple-jacketed wire) don't have to be rewired. This shielded wire will work if properly terminated. Total I/O wiring length cannot exceed 1000 ft (300 m).
  • Page 104 Chapter 6 Installing the EX2 expansion module Figure 49. I/O bus wiring example 2 BAS-APG001-EN...

  • Page 105: Setting The I/O Bus Addresses

    Setting the I/O bus addresses Setting the I/O bus addresses Each EX2 on the link with the Tracer MP581 must have a unique address. Configure the address using the DIP switches on the EX2 circuit board (Figure 50). Table 23 shows the DIP switch settings for expansion modules 1 through 4.

  • Page 106: Universal Inputs

    Configure each analog output and universal input using a LonTalk ser- vice tool, such as Trane’s Rover service tool. The service tool requires the Tracer MP581 software plug-in to configure an EX2. EX2 modules receive their configuration information from the Tracer MP581 controller they communicate with.
  • Page 107 Analog output and universal input setup Figure 51. Typical input/output terminal wiring diagram for the EX2 expansion module BAS-APG001-EN...

  • Page 108: Interpreting Ex2 Leds

    Chapter 6 Installing the EX2 expansion module Interpreting EX2 LEDs The information in this section will help you interpret LED activity on the EX2 expansion module. Figure 52 shows the location of each LED. Figure 52. LED locations on the EX2 Binary output LEDs Status LED TX and RX...

  • Page 109: Status Led

    Interpreting EX2 LEDs Status LED The Status LED on the EX2 module operates differently from the status LED on LonTalk devices. Table 25 describes EX2 Status LED activity. Table 25. Status LED LED activity Explanation LED is on continuously Power is on and the unit is operating normally. LED blinks twice The EX2 has not received its configuration from the Tracer MP580/581.
  • Page 110 Chapter 6 Installing the EX2 expansion module BAS-APG001-EN...

  • Page 111: Chapter 7 Programming

    Chapter 7 Programming Programming occurs after hardware installation is complete. The smoke control system must be programmed for automatic response, weekly self- testing, end-process verification, and response to manual FSCS commands. Response times Time response requirements must be kept in mind when programming. They are give in Table 27.

  • Page 112: Operational Priority

    Chapter 7 Programming In general, the BCU cannot pass information faster than every 5 seconds. This is the fastest a CPL routine can run. A BCU is included to collect system events, such as communication failure, and allow a user a remote connection to the system for status.

  • Page 113: Subsequent Alarms

    Subsequent alarms Table 28. Operational priority Current state of system Manual Automatic HVAC System self-test Panel lamp test override smoke alarm (nondedicated) Actuator is System self-test Panel lamp test Actuator is Manual override overridden. ends. can continue. overridden. Affects all non- System self-test Panel lamp test HVAC system...
  • Page 114 Chapter 7 Programming The wireless connector, smokeAlarmFloor, is used for the following two reasons: • Because smokeAlarmFloor clears the floor alarms value one program execution sooner than when using just the binary variable, smoke AlarmAllFloor To send a smoke alarm to any floor (see Figure 54 on page 103). •...

  • Page 115: Smoke Alarm Annunciation

    Smoke alarm annunciation Smoke alarm annunciation Systems serving two or more zones shall visually identify the zone of origin of the status change (UL-864: 33.2.1). The visual annunciation shall be capable of displaying all zones having a status change (UL-864: 33.2.2).
  • Page 116 Chapter 7 Programming From requirements 33.2.1 and 33.2.2, we can see that there is a decoupling between annunciation and reaction. The series of network variables shown in Figure 54, nvoSwitch05 through nvoSwitch12, are used to directly control the smoke alarm LEDs on the FSCP. For example, a smoke alarm for floor 1 is received.

  • Page 117: Weekly Self-Test Of Dedicated Systems

    Weekly self-test of dedicated systems Weekly self-test of dedicated systems (UL-864: 49.7) Dedicated smoke-control systems shall employ a weekly automatic self- test (AST). The AST automatically commands activation of each associated function. An audible and visual trouble signal shall be annunciated at the FSCP, identifying any function that fails to operate within the required time period.
  • Page 118 Chapter 7 Programming (On/Off), self-test enable, and self-test reset. Damper direction and fan state are set to Open/On for 5 minutes then Close/Off for 5 minutes. There is also a “blink” function built into the program fragment. Whenever the AST is enabled and there are no mechanical faults, the trouble LED will blink.
  • Page 119 Weekly self-test of dedicated systems [Figure 57 needs to be introduced.] Figure 57. ast overridesense 3-13-2006 BAS-APG001-EN...
  • Page 120 Chapter 7 Programming Figure 58 illustrates how adding self-testing to the system affects programming for damper control on each floor. The self-test request becomes another source of damper/fan control, along with automatic and manual override self-tests. The existence of the self-test signal is indicated by the binary variable, “selfTestEnable”.

  • Page 121: End Process Verification

    End process verification End process verification End process verification confirms that a device responded to an operation command. End process verification programming consists of: Programming the system to test binary input points for responses to • commands sent to output points Setting a counter to provide a time delay that allows the system time •...
  • Page 122 Figure 59 illustrates a basic actuator failure routine. Some changes are necessary when automatic self-testing is added to the program. The different ways of controlling an actuator have different means of resetting a failure. The failure reset is automatic if a failure is discovered during an automatic smoke alarm response or manual override from the smoke control panel.
  • Page 123 End process verification Figure 61. ast actuator fail checkb 3-13-06 BAS-APG001-EN...

  • Page 124: Communication Watchdog

    Chapter 7 Programming Communication watchdog Since multiple Tracer MP581s are used to interface with the mechanical equipment and FACP and FSCS panels, checking communications between each MP581 and BCU is necessary. Three different communication systems are used: BCU to MP581 (auto-bind), MP581 to MP581 (custom bind), and MP581 to EX2.
  • Page 125 Communication watchdog Figure 62. Watchdog communication relationship between a system MP581 and the central FSCP control MP581 Figure 63. Sample TGP showing transmitting during watchdog communication process] Figure 64. Sample TGP showing watchdog signal receive process There are three communication signals used in the smoke control system: BCU to MP581, MP581 to MP581, and MP581 to EX-2.
  • Page 126 Chapter 7 Programming information. A program fragment illustrating the collection process is shown in Figure 65. Figure 65. Collection of Tracer and EX2 communication status at an individual MP581 Figure 65 also shows that each MP581 in the smoke control system should send back its won watchdog signal to the main FSCP control MP581.
  • Page 127 Communication watchdog Figure 66. Determining overall communication status for the system Finally, the FSCP Comm Fault LED is controlled. A sample TGP fragment is shown in Figure 67. The FSCP Comm Fault LED is also controlled by the lamp test function. If a lamp test is not currently running, the FSCP Comm Fault is controlled by the overall communication status of the system.

  • Page 128: Lamp Test And Audio Alarm Silence

    Chapter 7 Programming Lamp test and audio alarm silence A lamp test must be performed for every FSCS panel. This test will cause all indicator lights to come on. However, an alarm takes precedence over the lamp test. Figure 68 shows a TGP program fragment that will enable a lamp test relevant to its own LEDs while broadcasting a lamp test request to other Tracer MP581s.
  • Page 129 Lamp test and audio alarm silence Triggering a lamp test affects all LEDs on the smoke control panel. Figure 69 shows an example of how to use the lamp test signal in combination with any smoke alarm information. Note: Note that the lamp test is not allowed to start or run if there is a smoke alarm.

  • Page 130: Nondedicated Smoke Purge

    Chapter 7 Programming Nondedicated smoke purge (UL-864: 3.21.h) The term nondedicated refers to a system that provides the building’s HVAC functioning under normal conditions and a smoke control objective during a fire alarm condition. The main concern when designing a nondedicated system is for programming to ensure that, once a smoke alarm or FSCP override occurs, any component of the smoke control system is controlled solely by automatic smoke control or manual override commands.

  • Page 131: Variable-Air-Volume System

    Variable-air-volume system Variable-air-volume system For variable-air-volume (VAV) systems, some form of duct pressure relief is required on each floor or in each smoke control zone. In smoke control mode, all return and supply fans will be set to their highest speed. If the VAV dampers are closed when this occurs, the duct pressure may be enough to damage the ductwork.
  • Page 132 Chapter 7 Programming BAS-APG001-EN...

  • Page 133: Chapter 8 Network Variable Bindings

    Chapter 8 Network variable bindings Overview The LonTalk communications protocol allows data to be shared between devices (stand-alone or with a BAS) on a LonTalk network. This is called peer-to-peer communication. As an example of peer-to-peer communica- tion, two or more devices serving the same space share data, such as a temperature reading, without having to pass the data through a BAS.

  • Page 134: Tracer Mp580/581 Bindings

    Chapter 8 Network variable bindings Tracer MP580/581 bindings This section discusses which network variables will be necessary to achieve UUKL time performance requirements. Only “generic” network variables, which are neither Space Comfort Controller (SCC) or Discharge Air Controller (DAC), are necessary. Use of generic variables does not affect either BCU auto-bound network variables or SCC or DAC based network variables.

  • Page 135: Custom Bindings

    Custom bindings Custom bindings A distinction is made between FSCP and mechanical system control in this section. While smoke control panel processing is predictable, mechanical system processing (actuators, feedback validation) is unknown. It is limited to approximately five smoke control zones based on the UUKL-approved smoke control panel.
  • Page 136 Chapter 8 Network variable bindings In Table 31, the term multi-vibrator is used to indicate a network variable whose state is changed regularly. The receiver expects this value to change state within a certain interval. If it does not, a communication fault is generated.
  • Page 137 Custom bindings Figure 71. Watchdog communication in a hub-based system MP580-B MP580-A Mechanical MP580-1 system System hubs Smoke control panel interface MP580-2 MP580-3 MP580-4 BAS-APG001-EN...

  • Page 138: Uukl Binding List (Smoke Alarm Status)

    Chapter 8 Network variable bindings UUKL binding list (smoke alarm status) Table 32 shows an example list of smoke alarm custom bindings. In order to comply with UL-864 annunciation and control requirements, smoke alarm signals are sent to the mechanical system, FSCP lamps, and audio alarms (Sonalerts).

  • Page 139: Uukl Binding List (Fcsp Override Control)

    Custom bindings UUKL binding list (FCSP override control) Table 33 shows an example list of FSCP override custom bindings. Override commands from the FSCP are sent directly to the mechanical system. Table 33. FSCP override custom bindings Function Originator Network variable Destination supplyFanManControl MP580-3...

  • Page 140: Uukl Binding List

    Chapter 8 Network variable bindings UUKL binding list (actuator Open/Close or On/Off status) Table 34 shows an example list of actuator status custom bindings. Actuator Open/Close or On/Off status is sent from the mechanical system directly to the FSCP. Table 34. Actuator status custom bindings Function Originator Network variable...

  • Page 141: Uukl Binding List (Actuator Failure Status)

    Custom bindings UUKL binding list (actuator failure status) Table 35 shows an example list of actuator failure status bindings. Actuator failure status is sent directly from the mechanical system to the FSCP. Table 35. Actuator failure status bindings Function Originator Network variable Destination supplyFanFail...

  • Page 142: Uukl Binding List (Automatic Self-Test Trigger And Status)

    Chapter 8 Network variable bindings UUKL binding list (automatic self-test trigger and status) Table 37 shows an example list of actuator failure status bindings. Only dedicated smoke control systems require a scheduled self-testing. Once the self-test is triggered, a status signal is sent to the panel trouble LED to blink.

  • Page 143: Node

    Nodes can be any LonTalk-compatible devices, such as appliances, switches, sensors, Tracer MP581s, and Tracer Summit BMTX BCUs, that are connected to a Trane LonTalk network. For the purposes of a UUKL- compliant system, a node is either a Tracer MP581 or a Tracer Summit BMTX BCU.
  • Page 144 Chapter 8 Network variable bindings targets can be either input NVs or output NVs, depending on the shape of the binding. For a one-to-one binding, the hub/target model loses its meaning, and either side of the binding could be the hub or the target. The Rover service tool does not indicate the shape or the type of the binding.

  • Page 145: Designing Bindings

    • Use Domain at Index: This number represents a pointer or reference to a table entry in the Domain table. For Trane devices, the value at index (or row) 0 will be a decimal 17. Group Number or Subnet Address field: The function varies •...
  • Page 146 Chapter 8 Network variable bindings A unique subnet/node binding type is a specific path from device X to device Y. Any number of actual network variable bindings could be built upon this path (see below). Regardless of the number of bindings built on a given path, only one address table entry will be consumed on the sending device.
  • Page 147 Understanding bindings Figure 74. One-way subnet/node binding In the example shown in Figure 75 on page 135, the custom bindings consume an address table entry in both MP581-A and MP581-B. Both MP581s are now transmitters of data. Both are subnet/node bindings. Figure 75.
  • Page 148 Chapter 8 Network variable bindings Figure 76. Group binding Groups are unique. Two unique groups are shown in Figure 77. One consists of MP581-A, B, and C while the other has members MP581-A, B, C, and D. Even though one is a subset of the other, it is set apart by having a different amount of members.
  • Page 149 Understanding bindings Figure 77. Group binding uniqueness When a group binding is made, all members of the group have an entry in their address table defining which group, what their member number is within that group and size of the group. Once this entry is made, any member of the group can now transmit information to the other members within that particular group.
  • Page 150 Chapter 8 Network variable bindings made, each member of the group has a entry made in its address table. For this example, all the devices are in Group 1. Now the user defines a second group binding with Device B transmitting nvoSwitch01 to Device A and Device C.
  • Page 151 Understanding bindings Figure 79. Mixed subnet/node and group bindings BAS-APG001-EN...
  • Page 152 Chapter 8 Network variable bindings BAS-APG001-EN...

  • Page 153: Appendix A References

    Appendix A References Huggett, C. 1980. Estimation of Rate of Heat Release by Means of Oxygen Consumption Measurements, Fire and Materials, Vol. 4, No. 2, June. Klote, J.H. 1994. Method of Predicting Smoke Movement in Atria With Application to Smoke Management, National Institute of Standards and Technology, NISTIR 5516.
  • Page 154 Appendix A References BAS-APG001-EN...
  • Page 156 For more information, contact your local Trane Trane has a policy of continuous product and product data improvement and reserves the right to office or e-mail us at comfort@trane.com change design and specifications without notice. Only qualified technicians should perform the installa-...
