Chapter 10: Monitor and Meter Sections
Monitor Section Controls
The Monitor section includes a full set of controls for the control room monitoring, headphone/cue, and talkback/listenback
sections of D-Command. All input and output connections to the D-Command monitoring system are made on the XMON in-
terface, which is connected to the D-Command console with the XMON cable, and remotely controlled from this section.
Output Channel Select
Input source switches
Cue
Talkback/Listenback
and Mode switches
and Output controls
controls
controls
Monitor
Mode
controls
D-Command Monitor section
