To exit the External Ethernet test:
Press the flashing Soft Key (Main Unit) or encoder Select
switch (Fader Module).

Switch and LED Test Page

The Switch and LED Test page has five modes:
• Switch: Switch Test Mode
• Red: Red LED Test Mode
• Yellow: Yellow LED Test Mode
• Green: Green LED Test Mode
• Vegas: Vegas Mode
To display the Switch and LED Test page:
From the Test Setup page, press the Soft Key (Main Unit) or
encoder Select switch (Fader Module) that corresponds to
"LED."
To exit the Switch and LED Test page:
Press the Soft Key (Main Unit) or encoder Select switch
(Fader Module) that corresponds to "Escape."
To enter any of the Switch and LED Test modes:
Press the Soft Key (Main Unit) or the encoder Select switch
(Fader Module) that corresponds to the mode name.
Switch Test Mode
Switch Test mode lets you test each switch on the unit indi-
vidually.
To test any switch:
Press the switch you want to test.
The switch LED lights as long as it is held and the Soft Key dis-
play (Main Unit) or encoder displays (Fader Module) show the
location information for the switch.
To exit Switch Test mode:
Press the Soft Key (Main Unit) or encoder Select switch
(Fader Module) that corresponds to "Escape."

LED Test Modes (Red, Yellow, Green)

The LED Test modes lets you test all red, yellow, and green
LEDs on the unit individually.
To test LEDs:
Press the Soft Key that corresponds to "Red," "Yellow," or
"Green" to test all LEDs of the corresponding color.
114 D-Command Guide
To exit LED Test mode:
Press the Soft Key (Main Unit) or encoder Select switch
(Fader Module) that corresponds to "Escape."
Vegas Mode
Vegas mode randomly lights every switch, meter, and display
on the unit, and runs the faders in sine wave mode.
To enter Vegas mode:
Press the Soft Key that corresponds to "Vegas."
To exit Vegas mode:
Press any switch on the unit.

Display Test Page

The Display Test page has three modes:
• Text: Display Test
• Time Code: Time Code Display Test
• Meter: Meter Bridge LED Test
To display the Display Test page:
From the Test Setup page, press the Soft Key (Main Unit) or
encoder Select switch (Fader Module) that corresponds to
"Disply."
To exit the Display Test page:
Press the Soft Key (Main Unit) or encoder Select switch
(Fader Module) that corresponds to "Escape."
To enter any of the Display Test modes:
Press the Soft Key (Main Unit) or the encoder Select switch
(Fader Module) that corresponds to the mode name.

Text (Display) Test

The Text test mode cycles through a series of display tests that
check all displays on the control surface.
To exit Text Test mode:
Press any flashing Soft Key (Main Unit) or encoder Select
switch (Fader Module).
Meter Bridge LED Test
The Meter Bridge LED test cycles through a series of auto-
mated tests that check all LEDs on each meter.
To exit Meter Bridge LED Test mode:
Press the Soft Key (Main Unit) or encoder Select switch
(Fader Module) that corresponds to "Escape."
