Dynamics Channel Select Controls; Dynamics Display; Lock Switch; Channel Select Switches - DigiDesign D-Command Manual

Dynamics Channel Select Controls

Save and Save As switches
Master Link switch
Channel Select controls in the Dynamics section

Dynamics Display

The LED display in the Dynamics section show the name of
the focused plug-in by default. When any rotary encoder is
touched, the display shows the corresponding parameter
value.

Lock Switch

The Lock switch is used to lock the focus of the Dynamics sec-
tion on the current plug-in. When the plug-in focus is locked,
the current plug-in remains in the Dynamics section, even
when a different track is focused on D-Command. This switch
lights when the plug-in focus is locked.
Save and Save As Switches
The Save and Save As switches perform the Save and Save As
commands in the Plug-in settings menu. The Save command
saves current parameter settings to the current plug-in settings
file, and the Save As command saves the parameter settings to
a new plug-in settings file.
To save a Dynamics plug-in setting from D-Command:
Press the Save or Save As switch in the Channel Select con-
1
trols of the Dynamics section. The Save or Save As switch
flashes while the Save Settings dialog is open.
Type a name for the plug-in setting.
2
Do one of the following:
3
• Click OK to save the settings and close the dialog.
• Press the flashing Save or Save As switch to save the set-
tings and close the dialog.
• Press the Escape switch to exit the dialog without saving
the settings.
56 D-Command Guide
Dynamics display
Lock switch

Channel Select switches

Select/Link/Bypass Mode switch
Bypass indicator
Channel Select Switches
Multichannel Plug-ins
When you are working with a multichannel plug-in, all chan-
nels are controlled in tandem and the Channel Select switches
have no effect.
Multi-Mono Plug-ins
When you are working with a multi-mono plug-in, the con-
trols for the channels are usually linked and edited together.
However, you can edit plug-in settings for individual channels
of a multi-mono plug-in by using the Channel Select switches
to unlink all of the channels, or to link specific channels.
There are Channel Select switches for the following channels:
• L (Left)
• C (Center)
• R (Right)
• Ls (Left Surround)
• Rs (Right Surround)
• LFE
A maximum of six channels (5.1 surround) may be in use at
any time.
