XMON Back Panel
The back panel of the XMON interface includes connectors for all external analog audio inputs and outputs for D-Command. See
"Audio Connections" on page 19.
Cue Inputs
Cue Outputs
Figure 5. XMON back panel
12
D-Command Guide
Main Inputs
Surround Inputs
Main Outputs
Alt Outputs
Talkback/
Listenback/
Utility
Stereo Inputs
Meter Calibration
Control Surface
Screws
AC Power
