Designing Labels Using LDS
))))))))))))))))))))))))))))))))))))))))))))
Starting position definitions:
Table 6 shows how to obtain proper character placement relative to orientations and
justifications.
Character Starting Positions Relative to Field Orientations and Field Justifications
Rotation
0,180 Degrees
90,270 Degrees
CMX CHARACTER MULTIPLIER X DIRECTION
This parameter multiplies each character in the X direction. A 5 high by 3 wide
character with a CMX of 2 would produce a 5 high by 6 wide character.
CMY CHARACTER MULTIPLIER Y DIRECTION
This parameter multiplies each character in the Y direction. A 5 high by 3 wide
character with a CMY of 2 would produce a 10 high by 3 wide character.
CS CHARACTER SPACING
This parameter adjusts the spacing between each character. If this parameter is not
used, then the default for the selected character generator (CGN) is used. Bar codes
have default spacing according to the indicated multiplier. Multiplying a text string will
not multiply the spacing between characters. This element should be used to properly
space the characters.
))))))))))))))))))))))))))))))))))))))))))))
28
Field Orientation and Justification
0 - Left justified above base-line
1 - Right justified above base-line
2 - Left justified below base-line
3 - Right justified below base-line
4 - Centered above base-line
5 - Centered below base-line
0 - Left justified above base-line
1 - Right justified above base-line
2 - Left justified below base-line
3 - Right justified below base-line
4 - Centered on Y axis, right of X coordinate
5 - Centered on Y axis, left of X coordinate

Character Starting Positions

Table 6
Chapter 4
470 Operators Manual
