Printer Commands
))))))))))))))))))))))))))))))))))))))))))))
information with all the fixed text data. Terminate the file with an ESCAPE character.
Now the variable data may serially be sent to the file. It may be the difference between
sending two lines of data versus the full 120 lines of the file! Access is very fast.
To read a file that has previously been sent to the printer, use the ^AX^D545
command, where ^AX denotes the file (slot #) to be read. The printer will send the file
to the serial port. If you are using a terminal or terminal utility, the file will be sent to
your screen.
Sample files: File #1 initiates the save format file memory and downloads saved format
file #1. File #1 includes all the fixed data on the label. File #2 is the file that initiates
processing of file #1 and includes all variable data for the format. File #2 also prints the
label.
File #3 shows how a second saved format would look. The data and processing
commands for file #3 are contained in file #4.
NOTE: <ESC> = 1B hex or ESCAPE character
File #1
^A1^D595
"sample"
^D575
4,288,193,5,19,30,0,1,1485
1,100,20,10,1,10,0,2,1,1,,15
1,210,20,7,1,10,0,2,2,2,,115
1,152,154,12,12,,0,2,2,100,,185
1,130,54,12,32,,0,2,2,2,,185
^D565
<ESC>
))))))))))))))))))))))))))))))))))))))))))))
58
