Circular Bar Code Attribute Numbers - Microcom 470 Operator's Manual

Chapter 4
))))))))))))))))))))))))))))))))))))))))))))
TSP TEXT STARTING POSITION
This parameter marks the starting position of the character in the text string to be used
as data. This is useful for allowing several fields to use sections of the same text string,
minimizing the amount of data transmitted. For example, for the text string
0123456789, A TSP of 5 and a CC (character count) of 2 would print 45. See section
5.3.4 for use of this parameter with clock fields.
AN ATTRIBUTE NUMBER
If this parameter is set to a value of 1, the image will be printed as if reflected in a
mirror. If set to a 2, the field can be printed white on black. If set to a 3, both mirror and
white on black options will be selected. A value of 0 is normal. Bar codes can also be
printed in a circular pattern by setting the value as follows:
PS PROPORTIONAL SPACING (Text Only)
If this parameter is set to a value of 1, text characters will be proportionally spaced. If
set to a 1, they will be non-proportionally spaced.
))))))))))))))))))))))))))))))))))))))))))))
470 Operators Manual
TCI Value
8 Full Circle
9 Upper Half
10 Right Half
11 Lower Half
12 Left Half

Circular Bar code Attribute Numbers

Table 7
Designing Labels Using LDS
Effect
29
