Placing the System

Before you set up your system, determine where you want to place it. Keep these guidelines
in mind:
u
Place the system as close as possible to the proper power outlet. The power cord
connecting the system to the facility power outlet or other power source serves as the
disconnect device.
u
Place the system in an area where air can circulate freely around it.
u
For a deskside installation, the front of the system requires at least twelve inches
clearance, and the back of the system requires at least eight inches clearance.
For rack mounting, ensure that the front and the back of the rack each have 36 inches of
clearance for servicing the installed hardware.
u
Do not expose the system to high levels of dust, smoke, or moisture.
u
Place the system in an area where the temperature range stays between 10 C and 26 C
(50 F and 80 F). The optimum operating temperature is 21 C (70 F).
u
Place the system in an area where the humidity stays between 20 percent and 80 percent
(non-condensing). The optimum operating humidity is 50 percent (non-condensing).
Install the system as described in "Setting up a Deskside System" or "Installing a System
into a Rack."

Understanding Power Requirements

The following table shows your system's rated power consumption (load).
Voltage
(Vac)
90
100
120
220
240
254
The power load of a device is the product of its operating voltage (such as 110 Vac) times its
current (such as 3 Amps). The rated power load of an external option (tape libraries, disk
arrays, and so on) is printed on back of the device.
Frequency Rated Current
(Hz) (Amps)
60 10
60 10
60 10
60 5
60 5
60 5
Rated Load
(VA)
900
1000
1200
1100
1200
1270
