Stereo Sync Output Port

The stereo sync output port is a female, 3-pin, mini-DIN connector. The port provides connection
to the emitter module of a pair of LCD shutter glasses or to other stereo shutter devices.
Pin Signal Name
1 +5V
2 Ground
3 Stereo Sync
GND
Sync
+5V
