Getting Started

This chapter introduces the Wildcat 4105 graphics accelerator and describes what you need to use
it in your workstation.

System Requirements

To use the Wildcat 4105, you will need:
A workstation running on Intel's Pentium
Microsoft Windows NT
Service Pack 3 and the appropriate QFE product (QFE_INTENS4K) installed
An AGP slot to insert the Wildcat 4105 and an open adjacent PCI slot for cooling purposes
A minimum of 32MB DRAM (64 MB recommended)
An industry-standard, multiple-frequency monitor
3 MB of free space on the computer's primary system disk for the Wildcat 4105 video display
driver software

Features

The Wildcat 4105 offers the following high-end graphics features.
Support for Windows NT graphics – Graphic Device Interface (GDI) and OpenGL
Support for resolutions up to 1.3 megapixels (1280 x 1024)
Support for graphics features such as Gouraud shading, 2D and 3D vectors and triangles,
texture processing, rectangle fills, antialiased vectors, clipping, alpha blending, fog, and
stenciling
16 MB of Synchronous Dynamic RAM (SDRAM) frame buffer memory and 64 MB of
SDRAM texture memory
Video plane sets of 128 bits per pixel (up to 1152 x 864) and 100 bits per pixel (at 1280 x
1024)
Four video lookup tables
10-bit gamma correction
32-bit double-buffering and 32-bit Z-buffering at 128 bits per pixel (up to 1152 x 864) or 24-
bit double-buffering and 24-bit Z-buffering at 100 bits per pixel (at 1280 x 1024)
Integrated VGA video support
®
II (or later) processor or equivalent
®
Workstation 4.0 operating system with Service Pack 4 (or later), or
