8
Removing and Installing Cards
To remove an installed Intense3D Wildcat 4105 card:
1.
Turn off power to the workstation and to the monitor.
2.
Open the workstation to gain access to the AGP slot.
3.
Remove the existing card. Keep the screws; you will use them to secure the card to the
workstation's chassis later.
To install the Intense3D Wildcat 4105 card:
1.
Align the card with the AGP expansion slot, making sure the gold-fingered connections on the
card's edge are aligned properly with the slot connector.
2.
Push the card into the AGP slot firmly and evenly until it is fully seated in the AGP slot
connector.
3.
Visually inspect the connection. If it does not appear to be correct, remove and reinstall the
card.
4.
Use the screws you removed previously to secure the card to the workstation's chassis.
