T1 CSU/DSU ASE specifcations
Dimensions
General
Weight
Data Rate
Timing Mode
Operating Temperature
Environment
Storage Temperature
Clearance Requirement
Operating and Storage
Humidity
Input
Power Requirements
Frequency
Input Current Rating
T1 Network Interface Line Rate
Line Format
Framing
ESF FDL
Input Signal
Output Signal
Pulse Density
Connector
Timing
Channel Selection
Network DTE Interface Confi guration
(Data Port)
Data and Clock Leads
Signaling Leads
Data Rates
HDLC Inversion
Transmit Timing Basis
Receive Timing Basis
Receive Line Data Not Valid
Connector
Specifi cations
Serial Port Interface
Bite Rate
Ethernet 10/100BaseT
Interface
Connector
8.16" (20.7 cm) x 9.0" (22.8 cm) x 1.62"(4.1 cm)
Plastic case with internal power supply.
2.10 lbs.
1.544 Mbps synchronous
Derived externally from the T1 network or DSX-1
interface, or internally from the ASE.
o o o o
0 to +40 C (+32 to +104 F)
o o o o
-20 to +55 C (-4 to +131 ×F)
Minimum of 3" (7.62 cm) space on sides.
10% to 90%, noncondensing
100 to 120 VAC
50/60 Hz
0.5 amps
1.544 Mbps ±50 bps synchronous
AMI or B9ZS line coding
ESF or D4 framing formats
ANSI T1.403, AT&T TR54016, Both, or None
0dB to -36dB
0, -7.5dB, -15dB, -22.5dB LBO
AT&T 62411
8-pin modular jack—USOC: RJ48C
Loop, DSX-1, or Internal
1 to 24 channels in any combination
DCE for interfacing with DTE
ITU-T V.35
EIA RS-232 (ITU-T V.28)
56 kbps x N or 64 kbps x N (N = 1 through 24)
Selectable V.35 data inversion
Network selected-source timing
SCT, inverted SCT, SCTE
RLSD, CTS
Female 34-pin V.35 connector
19200 or 9600 bps baud rate, 8 data bits no parity,
1 stop bit, EIA RS-232 DTE electrical format, RJ-45
connector
10 or 100 Mbps
8-pin modular jack: RJ-48
What are ASEs?
ASEs (Analysis Service Elements) are data
collection and network performance monitor-
ing hardware devices placed on a wide area
network (WAN) or Local Area Network (LAN)
as part of the Visual UpTime Select system,
which offers in-depth, real-time, and historical
visibility into the performance of your
applications infrastructure. In the system,
data gathered by ASEs is stored in the Visual
UpTime Select server and displayed and ana-
lyzed from the Visual UpTime Select Web client.
As a service level management tool, ASEs
indicate when services are being met, provide
warnings when services start to degrade, and
send alerts when services are not met.
Hardware Warranties
Enhanced Gold, Bronze, and International
Gold ASE hardware warranty service programs
are available to help you maximize your
investment in Visual UpTime Select. For more
detailed warranty information, visit:
www.fl ukenetworks.com/visualcustomercare
Ordering Information
For more details, please contact your Visual
UpTime Select authorized reseller or
Fluke Networks Sales at (800) 240-4010
or (301) 296-2300.
