Fluke Visual UpTime Select 807-0115 Brochure & Specs page 12

HSSI inline probe ASE specifcations
Dimensions
General
Weight
Data Rate
Timing Mode
Operating Temperature
Environment
Storage Temperature
Clearance Requirement
Operating and Storage
Humidity
Input
Power Requirements
Frequency
Input Current Rating
HSSI Interface Confi guration
Baud Rate
Serial Port Interface
Parity
Stop Bit
Electrical Format
Connector
Ethernet 10/100BaseT Bite Rate
Interface
Connector
17.3" (43.9 cm) x 12" (30.5 cm) x 3.5" (8.9 cm)
10.45 lbs.
0 to 44.736 Mbps synchronous
RD: Always synchronous with SCR
SD: Synchronous with SCT or SCTE
o o o o
0 to +40 C (+32 to +104 F)
o o o o
-20 to +55 C (-4 to +131 ×F)
Minimum of 3" (7.62 cm) space on sides.
10% to 80%, noncondensing
100 to 240 VAC
50/60 Hz
1 amp
Two HSSI interfaces: one DTE and one DCE for
monitoring to-network and from-network traffi c.
19200 or 9600 bps
8 data bits, no parity
1 stop bit
EIA RS-232, DTE
9-pin D, male per EIA-574
10 or 100 Mbps
8-pin modular jack: RJ-48
What are ASEs?
ASEs (Analysis Service Elements) are data
collection and network performance monitor-
ing hardware devices placed on a wide area
network (WAN) or Local Area Network (LAN)
as part of the Visual UpTime Select system,
which offers in-depth, real-time, and historical
visibility into the performance of your
applications infrastructure. In the system,
data gathered by ASEs is stored in the Visual
UpTime Select server and displayed and ana-
lyzed from the Visual UpTime Select Web client.
As a service level management tool, ASEs
indicate when services are being met, provide
warnings when services start to degrade, and
send alerts when services are not met.
Hardware Warranties
Enhanced Gold, Bronze, and International
Gold ASE hardware warranty service programs
are available to help you maximize your
investment in Visual UpTime Select. For more
detailed warranty information, visit:
www.fl ukenetworks.com/visualcustomercare
Ordering Information
For more details, please contact your Visual
UpTime Select authorized reseller or
Fluke Networks Sales at (800) 240-4010
or (301) 296-2300.
