4xT1/E1 inline probe ASE specifcations
General Dimensions
Weight
Data Rate
Timing Mode
Operating Temperature
Environment
Storage Temperature
Clearance Requirement
Operating and Storage
Humidity
Input
Power Requirements
Frequency
Input Current Rating
T1 Network Interface Line Rate
(Ports 1-4)
Line Format
Framing
Input Signal
Output Signal
Pulse Density
Connector
Timing
Channel Selection
Line Rate
E1 Network Interface
(Ports 1-4)
Line Format
Framing
Time Slot 16
Input Signal
Output Signal
Connector
Channel Selection
Baud Rate
Serial Port Interface
Parity
Stop Bit
Electrical Format
Connector
Ethernet 10/100BaseT Bite Rate
Interface
Connector
8.16" (20.7 cm) x 9.0" (22.8 cm) x 1.62"(4.1 cm)
7 lbs.
T1: 1.536 Mbps, E1: 1.984 Mbps
Derived externally from the T1 or E1 network,
user interface, or internally from the ASE.
o o o o
0 to +40 C (+32 to +104 F)
o o o o
-20 to +55 C (-4 to +131 ×F)
Minimum of 3" (7.62 cm) space on sides.
10% to 80%, noncondensing
100 to 240 VAC
50/60 Hz
0.5 amps
1.544 Mbps ±50 bps synchronous
B8ZS line coding
ESF framing formats
0dB to -36dB
0, -7.5dB, -15dB, -22.5dB LBO
AT&T 62411
100 ohm 8-pin modular jack—USOC: RJ48C
Network or User
1 to 24 channels in any combination
2.048 Mbps ±102.4 bps synchronous
HDB3 line coding
CRC4 or FAS framing formats
CAS, CCS, or Data
0dB to -43dB
0dB
120 ohm RJ-48C balanced and 75 ohm BNC unbal-
anced coaxial
1-31 (includes channel 16) or 1-15, 17-31 (does
not include channel 16)
19200 or 9600 bps
8 data bits, no parity
1 stop bit
EIA RS-232, DTE
RJ-45
10 or 100 Mbps
8-pin modular jack: RJ-48
What are ASEs?
ASEs (Analysis Service Elements) are data
collection and network performance monitor-
ing hardware devices placed on a wide area
network (WAN) or Local Area Network (LAN)
as part of the Visual UpTime Select system,
which offers in-depth, real-time, and historical
visibility into the performance of your
applications infrastructure. In the system,
data gathered by ASEs is stored in the Visual
UpTime Select server and displayed and ana-
lyzed from the Visual UpTime Select Web client.
As a service level management tool, ASEs
indicate when services are being met, provide
warnings when services start to degrade, and
send alerts when services are not met.
Hardware Warranties
Enhanced Gold, Bronze, and International
Gold ASE hardware warranty service programs
are available to help you maximize your
investment in Visual UpTime Select. For more
detailed warranty information, visit:
www.fl ukenetworks.com/visualcustomercare

Ordering Information

For more details, please contact your Visual
UpTime Select authorized reseller or
Fluke Networks Sales at (800) 240-4010
or (301) 296-2300.
