About the IE-MediaChassis/1

The Industrial Ethernet IE-MediaChassis/1 is a compact and modular, single-slot table-
top unit that hosts a variety of IMC Networks iMcV-Modules. The IE-MediaChassis/1
has two power options: a 4-terminal DC power block, and a country-specific external
AC power adapter. In addition, IE-MediaChassis/1 also includes an extended voltage
range; an extended operating temperature; and DIN clips for mounting the enclosure
on a DIN rail. Deploy these standalone chassis at the customer premises (CPE) or
each access point.

Configuring and Installing Modules

To install a module (any iMcV series module except those that are double- wide),
slide the module into the chassis until the module is firmly seated in the backplane.
Secure the module to the chassis by tightening the captive screw.
Please refer to the installation guide online for the module for configuration
and operation information.
The power source in this chassis is not isolated, and cannot support positive
reference ground systems typically used in Telco environments. The
MediaChassis/2-DC and the iMediachassis/6-DC are suitable alternates.

Installing the IE-MediaChassis/1

IE-MediaChassis/1 installs virtually anywhere: as a standalone, table-top device, on a
DIN rail, or Wallmounted. As a table-top unit, install the IE-MediaChassis/1 by
placing it on a flat surface. Make sure to leave adequate space on top of the unit to
accommodate cooling. Attach the network cables between the module and other
devices that will be interconnected, and then plug the unit into a reliable, filtered
power source.
Wallmount Bracket Installation
Wallmount Brackets, an optional accessory available through IMC Networks (Part
number 895-39229) allow the IE-MediaChassis/1 to be Wallmounted. Refer to DIN
Rail Mounting diagram for this mounting option.
NOTE
