DIN Rail Mounting
The IE-MediaChassis/1 can be mounted with two DIN Rail clips, a hardware option
available through IMC Networks. The DIN Rail clips include screws, to allow the
installation onto a DIN Rail. Install the screws into DIN Rail clips, which should be
mounted perpendicular to the DIN Rail. Snap the converter onto the clips. To
remove the converter from the DIN Rail, use a flat-head screwdriver into the slot to
gently pry the converter from the rail.
The DIN clips are designed for use on a DIN-35 rail.
Wallmount Bracket

Powering the IE-MediaChassis/1

IE-MediaChassis/1 includes multiple powering options. Any of the following options
can be used, or more than one for redundancy:
•
A country-specific, high-reliability AC power adapter (included)
•
The 4-terminal DC power block
NOTE
Din Rail Mounting
