Specifications; Imc Networks Technical Support - IMC Networks IE-iMcV-MultiWay Operation Manual

Specifications

Ethernet Connections
• SFP 1000 Base-X
• SFP 100 Base –FX
• SFP 10/100/1000 Copper (SGMII)
• 10/100/1000 BaseT (Fixed Copper ports)
• Auto Negotiation
• Auto-Cross
• Flow Control
• Up to 10,240 MTU
• Full Line-Rate Forwarding
Power Consumption (Typical)
3.7W (731mA @ 5V)
Operating Temperature
-40°F to +185°F (-40°C to +85°C)
Storage Temperature
-67°F to +257°F (-55°C to +125° C)
Humidity
5 to 95% (non-condensing); 0 to 10,000 ft. altitude
Dimensions
Single Slot iMcV-Module
•
IEEE 802.3x Flow Control
•
IEEE 802.3i 10Base-T twisted pair
1-year warranty for SFP

IMC Networks Technical Support

Tel: (949) 465-3000 or (800) 624-1070 (in the U.S. and Canada);
+32-16-550880 (Europe)
Fax: (949) 465-3020
E-Mail: techsupport@imcnetworks.com
Web: www.imcnetworks.com
•
IEEE 802.3u 100Base-TX twisted pair
•
IEEE 802.3u 100Base-FX or SX fiber
52
