This screen contains the following information and options:
Saved and Current Values
Saved values display the changes made during the current session and current values
display the values currently in use:
•
IP Address (IP address of SNMP agent)
•
Subnet Mask (mask to define IP subnet to which agent is connected)
•
Default Gateway (default router for IP traffic outside of the subnet)
Command List
I = Enter new Saved Parameter Values
P = Change the Password*
T = Enter new Trap Destinations
K = Remove All Trap Destinations
C = Create SNMP Community Strings
U = Delete All SNMP Community Strings
E = End the session*
Reboot = Reboot the unit (may result in short data loss)
D = Enable or disable DHCP
Space Bar = Opens the device specific configuration options screen.
*The screens illustrated in this manual show capabilities for users with Admin
rights. Individuals with User-level rights can only view port status and port
settings, change their password, end a session, and reboot the unit.
It is necessary to reboot the IEiMcV--MultiWay after making any modifications to the Saved
Values for the changes to take effect. To reboot, type Reboot at the prompt on the Main
Configuration screen.
Assigning IP Information
To modify the Saved Parameter Values (i.e., assign IP address and subnet mask),
press I. The system prompts for the IP address and subnet mask for the connected
device. Press Enter after each entry. A default gateway can also be assigned, or press
Enter to skip. When finished, press Enter, then type reboot for changes to take
effect. The Current Values can only be saved and acted on after the IE-iMcV-
MultiWay has been successfully rebooted.
Password Protection for Serial Port Connections
Password/username is not offered for the serial port by default. This allows the end
user to quickly access the device for some basic configuration capability. Password
protection is provided for the serial configuration process by pressing P on the main
configuration screen. Enter a password, keeping in mind that passwords are case-
NOTE
11
