Troubleshooting

If the PoE+ Giga-McBasic is not responding to the power provided to it, the following
conditions may be responsible:
•
There may be an over current condition; this is indicated on the PSE LED by a
series of two flashes.
•
There may be an invalid low or high discovery signature resistance; this is
indicated on the PSE LED by a series of five flashes.
•
If the PoE injector has power that can be verified, but the PSE LED is off, then
contact IMC Networks technical support.

RJ-45 Pinouts

The following table lists the pin configuration for the RJ-48 connector.
Pin# Signal Name
1
2
3
4
5
6
7
8
Signal Direction
1000M 10/100M
TXD1+ Out*
TXD1- Out*
RXD2+
D3+
D3-
RXD2-
D4+
D4-
14
PoE
PoE+
(ALT-B)
IN*
+V
+V
In*
-V
-V
