About the PoE Giga-McBasic

The PoE Giga-McBasic is a solution for private network applications that require
power over Ethernet for installations inside buildings where PoE is required to power
an Ethernet device. The standalone unit offers a model with one SFP or fixed fiber
transceiver, 1x9, uplink for the network connection, one PSE 10/100/1000Base-T
copper port that provides Power-over-Ethernet (PoE) (IEEE802.3af), and one 10/100/
1000Mbps copper port, to connect a non-PoE unit to the same fiber uplink. As a
fiber-fed demarcation unit, it provides both power and data to a remote device over
a standard CAT5 copper line, eliminating the need for a power connection to the
remote device. The PoE Giga-McBasic provides up to 15.4 watts on one copper
port, and is powered by an internal power supply, supporting 100-240 VAC. For
more robust power requirements on both copper ports, refer to the information
about the PoE+ Giga-McBasic.
NOTE
Unless noted otherwise, any reference is applicable for both the 1x9 and SFP version of
the PoE Giga-McBasic in this manual.
The PoE Giga-McBasic is a solution for private network applications that require
power over Ethernet for locations inside buildings where PoE is required to power an
Ethernet device. The standalone unit offers a model with one SFP or fixed fiber
transceiver, 1x9, uplink for the network connection, one PSE 10/100/1000Base-T
copper port that provides PoE (IEEE802.3af), and one 10/100/1000Mbps copper port.
As a fiber-fed demarcation unit, it provides both power and data to a remote device
over a standard CAT5 copper line, eliminating the need for a power connection to
the remote device. The PoE Giga-McBasic provisions up to 15.4 watts on one copper
port, and can be powered by an external AC adapter or DC terminal block. For
more robust power requirements on both copper ports, please refer to the
information about the PoE+ Giga-McBasic.
The SFP uplink can support fiber or copper SFPs. The fiber SFP, available in SC or LC
connectors, supports 100FDX or 1000FDX; a copper SFP supports the SGMII
interface (10/100/1000Mbps). The SFP, with or without DDMI, is available for
purchase through IMC Networks Distributors. The SFP must be MSA-compliant.
The copper ports auto negotiate to the connected device's speed and duplex mode:
10 Mbps, 100 Mbps or 1000 Mbps, and HDX or FDX (including Flow Control). The
PoE+ Giga-McBasic supports jumbo frames up to 10240.
