Troubleshooting

•
PWR LED glows green when the unit is powered. If this LED is not lit, contact
IMC Networks Technical Support.
•
If the PSE LED flashes twice, it may indicate an over current condition. The PSE
LED should maintain solid green, to indicate consistent power. Check the PD
device and its requirements.
The following table lists the pin configuration for the RJ-48 connector.
Pin# Signal Name
1
2
3
4
5
6
7
8
Signal Direction
1000M 10/100M
TXD1+ Out*
TXD1- Out*
RXD2+
D3+
D3-
RXD2-
D4+
D4-
4
PoE
(ALT-B)
IN*
+V
+V
In*
-V
-V
