IMC Networks PoE Giga-McBasic Operation Manual page 6

Under no conditions will the LoSPd DSW impact any copper SFPs. Some 1000Mbps SFPs
may not function properly when forced to 100Mbps.
PoE Reset DSW
When set to ON, it will force the PSE output power on the copper port OFF when
the LINK state is lost on the SFP line (copper or fiber SFP). By default, the DSW is
set to OFF.
PoE Giga-McBasic 1x9
DIP Name
Switch
1 PoE Reset
2 Factory Set
3 Factory Set
4 Factory Set
5 Factory Set
6 Factory Set
7 Factory Set
8 Factory Set
PoE Reset DSW
When set to ON, it will force the PSE output power on the copper port OFF when
the LINK state is lost on the fiber segment. By default, the DSW is set to OFF.
NOTE
Description
ON forces Port 2,
PSE/PoE, to OFF on
LOS of Fiber input
Do not change
Do not change
Do not change
Do not change
Do not change
Do not change
Do not change
3
Default DIP Switch
Setting
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
