Zpwy-Ddl-On-Off; Zpwy-Ddl-On-Off-Current; Zpwy-Ddl-Owner-Id - HP NonStop Pathway/iTS Programming Manual

ZPWY-DDL- Definitions

ZPWY-DDL-ON-OFF

ZPWY-DDL-ON-OFF specifies whether a feature or capability (such as using an
Inspect process or TMF auditing) is enabled.
def ZPWY-DDL-ON-OFF
Values can be ZPWY-VAL-ON or ZPWY-VAL-OFF; their meanings are further
described in the fields in which they occur.
Note. ZPWY-VAL-ON is equivalent to ZSPI-VAL-TRUE, and ZPWY-VAL-OFF is equivalent to
ZSPI-VAL-FALSE, neither of which values are supported in COBOL. For information on
working with Boolean values and COBOL coding suggestions, see the SPI Programming
Manual.

ZPWY-DDL-ON-OFF-CURRENT

ZPWY-DDL-ON-OFF-CURRENT specifies whether to override the echo mode
configured for a device at system generation. This type applies to the TERM and
PROG objects.
def ZPWY-DDL-ON-OFF-CURRENT
The following values are valid:
ZPWY-VAL-ON
ZPWY-VAL-OFF
ZPWY-VAL-CURRENT

ZPWY-DDL-OWNER-ID

ZPWY-DDL-OWNER-ID is the user ID allowed to issue commands that directly alter
the state of PATHMON-controlled objects. The user ID must be known to the system in
which your management application is running.
def ZPWY-DDL-OWNER-ID.
02 ZSYSTEMNUMBER
02 ZGROUPNUMBER
02 ZUSERNUMBER
end.
NonStop Pathway/iTS Management Programming Manual—426749-002
token-type ZSPI-DDL-BOOLEAN.
token-type ZSPI-DDL-ENUM.
Causes input to appear on the output device.
Corrects the display by suppressing the duplicate characters
(if an output device is configured so that it normally displays
input characters).
If you define this option for the supported device types
T16-6520, T16-6530, and T16-6540, no input characters
appear on the screen.
Causes the TCP to obtain the operating mode of the output
device from the operating system and to use that mode
when the TCP opens the output device.
token-type ZSPI-DDL-INT.
token-type ZSPI-DDL-INT.
token-type ZSPI-DDL-INT.
5- 14
ZPWY-DDL-ON-OFF
