3

BASIC OPERATION

I Power ON

Push and hold [POWER]
for 1 sec. to turn power
ON.
• Current battery voltage is
displayed for 2 sec.
POWER
10
• The display shows the approx. volt-
age in 0.5 V steps.
• When the battery voltage is lower
than 4.5 V, "LOW V" appears.
Charge the battery in this case.
• If "OVER V" appears, UNPLUG the
external DC plug immediately.
Connected voltage is over 16 V and
could damage the transceiver.

I Setting a frequency

D Via the keypad
(within a band)
➀
Push [VFO] to select VFO
mode.
➁
Push [BAND] to select the
VHF or UHF band.
➂
Push 4 digit keys, starting
from the 1 MHz digit and
including the decimal point
[ • ], to input a frequency.
• When a digit is mistakenly
input, push [VFO] and input
from the beginning.
• "0," "2," "5" and "7" are accept-
able for the 1 kHz digits
(depending on the 10 kHz digit).
➃
To change the frequency
from the 100 kHz digit, push
[ • ], then 3 digits.
5
.
3
6
0
.
5
0
0
