2
BATTERY PACKS AND ACCESSORIES
D Operation with an optional cable
Connect an optional charger or cable to the transceiver as
illustrated below. Be careful of battery overcharging as the
connected battery is charged simultaneously.
CAUTION:
Remove dry cell batteries when the BP-170
is connected, otherwise the battery may
BATTERY CASE
leak and damage the transceiver.
*To charge the battery pack
12 to 16 V DC is necessary.
8
I Battery case
When using a battery case attached to the transceiver, install
LR6 (AA) size × 4 alkaline cells as illustrated below.
×
