6 – Performing Diagnostics
Viewing Logs
Last Update Time
Router IP Address The IP address of the router.
Router Lifetime
Flags
For more detailed information, refer to the
Specification
NOTE:
5. If you want to refresh the log information immediately, click Refresh.
6. To exit the log, click Close.

Viewing the IPv6 Local Prefix List Log

The IPv6 Local Prefix List contains prefix information obtained from router
advertisements. Destination IP addresses containing these prefixes can be
reached directly, without going through and intermediate router.
To view the prefix list log:
1. On the SANsurfer iSCSI HBA Manager main window HBA tree, select the
HBA port.
2.

Click the Diagnostics tab to bring the Diagnostics page to the front.

The top portion of the Diagnostics page contains the HBA port-identifying
information; for details, see
page
3. On the Diagnostics page, click the Logs tab.
The Logs page opens within the Diagnostics page (see
6-7).
4. On the Logs page, click Display Prefix List.
6-14
The date-time stamp of the last router list entry. The
date-time stamp is in 12 hour format.
The length of time, in minutes and seconds, that the
router can be used as the default router for this entry.
Valid entry=0x1; non-valid entry=0x0.
(see "Related Documents" on page
If text in any column is truncated, move the cursor over it to reveal the
entire text in a tool tip next to the cursor.
6-2.
ISP4xxx Firmware Interface
"General Information for the HBA Port" on
S
1-3).
Figure 6-4 on page
IS0054602-00 B
