C H A N N E L 1 D U A L F L O W
FLOW 1
VOLUME
FLOW 2
E l a p s e d T i m e
I n s t . F l o w
B a c k P r e s s u r e
STATUS GRAPH
3-32

Dual Rate Test Screen (Measuring Mode)

0.00
ml /h
0.00
0. 00 VOLUME
00: 00: 00
0. 00 ml /h
0. 00 psi
FLOW OCCL END
When the test is started, the screen enters measuring
mode for the primary flow rate (Flow 1) as shown. This
enables further menu options.
As the test progresses the IDA-4 Plus detects the
change in flow rate and changes the display to
ml
emphasize the secondary flow rate (Flow 2). The
Instantaneous Flow Rate shall be displayed in this
screen between the elapsed time and backpressure
readings.
Status
This invokes the STATUS ALL CHANNELS screen.
Graph
This switches to the DUAL FLOW GRAPH screen for
the current channel.
Flow
This ends the current test, clear the values from the
screen and proceeds to the FLOW TEST screen in
either Prime or Start mode, depending on the current
state of the transducer.
Occlusion
This ends the current test, clear the values from the
screen and proceed to the OCCLUSION TEST screen
in Wait mode.
End
Ends the test and advances to the End of Test Mode.
