U T I L I T I E S

RECALL TESTS

REPORT HEADER

SET CLOCK

RS232 PORT
LCD SETUP ENG TESTS
PRINTER TEST PARAMETERS
ESC
R e c a l l T e s t s
Control No Date
Dual Flow 03-Sep-03
Dual Flow 04-Sep-03
PCA Test 12 06-Sep-03
PRINT DELETE
WARNING
T h i s w i l l d e l e t e A L L r e s u l t s !
A r e y o u s u r e ?
NO
S e t C l o c k
D a t e 0 0 – J a n – 0 0 T i m e 0 9 : 5 7 : 2 5
U s e t h e l e f t a n d r i g h t a r r o w
k e y s t o s e l e c t .
Use the up and down arrow
keys to change.
P r e s s E N T E R t o A c c e p t

Utilities

This screen is displayed whenever UTIL is selected.
Using the arrow keys to move the cursor to the required
utility, in this case RECALL TESTS is selected, press
ENTER and the set-up screen for the chosen utility is
displayed.
Choosing ESC and pressing ENTER will default to the
STATUS ALL CHANNELS screen.
Recall Tests
The cursor is moved by pressing the up and down
buttons. When the required stored test is selected,
Time
pressing ENTER brings up the menu selections shown
14:31
at the bottom of the screen. User's then have the options
12:05
to PRINT text data, DEL or ESC and return to
10:45
UTILITIES main screen.
ESC
Note: If you select DEL and press ENTER a warning
screen is displayed as shown. Selecting YES and
pressing ENTER will DELETE ALL results. Make
sure you have printed or downloaded any records that
you need. Selecting NO returns to the UTILITIES
menu.
YES
Set Clock
To Set the Clock use the left and right keys to select the
item to be changed then the up and down keys to
change to the required setting.
When correct settings are achieved press ENTER to
accept these settings.
These settings cannot be altered once a test is in
progress.
Infusion Pump Analyzer
Operating Instructions
3
3-7
