IDA-4 Plus
Operators Manual
P r i n t e r
Page /
Cont
Page
U s e t h e l e f t a n d r i g h t a r r o w
Use the up and down arrow
P r e s s E N T E R t o A c c e p t
3-8
L C D S E T U P
M O D E
ESC
O p t i o n s
Lines Report
/Page Layout
55 Full
K e y s t o s e l e c t .
Keys to change.

LCD Set-up

Cursor defaults to MODE when this screen is selected,
pressing ENTER changes the screen mode to black on
white or white on black.
Choosing ESC and pressing ENTER accepts the mode
and contrast as displayed and returns the screen to
STATUS ALL CHANN

Printer Options

To Set printer Left Margin, Form Feed and Layout use
the left and right keys to select the item to be changed
then the up and down keys to change to the required
setting.
Page / cont
When 'page' printer is selected, a left margin is inserted
and a form feed sent at the end of each page. (See lines
/ page). This is suitable for most printers that use single
sheet or tractor feed paper.
When 'cont' is selected, the left margin is not inserted
and form feeds are not sent. This is suitable for most
narrow paper strip printers.
Lines / page
This allows the number of printed lines per page to be
adjusted.
55 lines allow U.S. letter or European A4 paper to be
used on most printers. There are some printers available
that have a slightly shorter printing area. Adjust lines /
page if the page size does not appear to be correct.
Layout
'Full' prints all data points collected. 'Summary' prints
sample data points evenly distributed throughout the
collected data, to fit the report on a single page.
When correct settings are achieved press ENTER to
accept these settings. Last accepted entries are stored
and can be changed as required via this screen
