Occlusion Test Screen (Start Mode); Occlusion Test Screen - Fluke Biomedical IDA-4 Plus Operator's Manual

IDA-4 Plus
Operators Manual
C H A N N E L 1 O C C L U S I O N
PRESSURE
TIME
Peak Pressure
Time of Peak
START
C H A N N E L 1 O C C L U S I O N
PRESSURE
TIME
Peak Pressure
Time of Peak
STATUS GRAPH
3-20

Occlusion Test Screen (Start Mode)

0.00
psi
00 : 00 : 00
psi
00: 00: 00
STATUS ESC
Occlusion Test Screen (Measuring Mode
0.00
psi
00 : 00 : 00
psi
00: 00: 00
FLOW OCCL END
When the transducer has completed its tare operation
the screen changes as shown.
Start
When the transducer has completed its tare
measurement the START option is enabled. Pressing
ENTER while this option is selected will start the
occlusion test and advances to the measuring mode.
Status
This invokes the STATUS ALL CHANNELS screen.
ESC
Selecting ESC or pressing the ESC key on the external
keyboard will take the operator back to the CHANNEL
SETUP menu.
When the test is started the screen enters the measuring
mode as shown. This enables further menu options.
Status
This invokes the STATUS ALL CHANNELS screen.
Graph
This switches to the OCCLUSION GRAPH screen for
the current channel.
Flow
This ends the current test, clears the values from the
screen and proceeds to the FLOW TEST screen in
either PRIME or START mode, depending on the
current state of the transducer. The results of the
subsequent test will be appended to those of the test
terminated by this option.
Occlusion
This ends the current test, clears the values from the
screen and proceeds to the OCCLUSION TEST screen
in Wait Mode. The results of the subsequent test will be
appended to those of the test terminated by this option.
End
Ends the test, or sequence of tests, and advances the
OCCLUSION TEST screen to the End of Test Mode.
