IDA-4 Plus
Operators Manual
Physical
Environmental
Transportability
If possible use the packaging supplied by the manufacturer. If this is not possible then enclose the
instrument in a clear plastic bag, and place it in a cardboard box with plastic packing materials,
with at least 5 cm (2 inches) between the instrument and the exterior of the box to protect against
shock. Remove all water before packing.
1-4
Dimensions: ~19.05 cm x 18.11 cm x 30.18 (L x W x H)
(for rear panel handle add 3.81cm)
Weight:
5.0 Kg (with 4 transducer fitted)
Case:
Molded plastic front panel, metal rear housing.
Color:
RAL 9002
Operational: 15-30 C up to 50% Relative Humidity
Storage:
0-40 C at 85% RH or less
Do not leave for more than 48 hours at -20 C
