Specifications, Accessories, Part Numbers, cont'd

Included Parts

These items are included in each order for an SCP control pad:
Included parts (SCP/AAP A)
SCP/AAP A (gray, black, white)
3.5 mm, 5-pole captive screw connectors
Included parts (SCP 200)
SCP 200 (gray, black, white)
2-gang electrical box
3.5 mm, 5-pole captive screw connectors
Included parts (SCP 250)
SCP 250 (gray, black, white)
3-gang electrical box
3.5 mm, 5-pole captive screw connectors

Accessories

Accessories
2-gang mounting bracket
3-gang mounting bracket

Cables

This is the type of cable recommended for connecting a system
switcher to one or more SCP control pads:
Comm-link cable
50 feet/15.2 meters long
100 feet/30.5 meters long
200 feet/61 meters long
400 feet/122 meters long
Bulk 500 feet/152.4 meters long
Bulk 1000 feet/304.8 meters long
SCP/AAP A, SCP 200, SCP 250 • Specifications, Part Numbers
A-4
Part number
60-339-01, -02, -03
10-319-10
Part number
60-338-01, -02, -03
10-319-10
Part number
60-356-01, -02, -03
10-319-10
Part number
70-086-01, -11, -21
(gray, black, white)
70-086-02, -12, -22
(gray, black, white)
Part number
26-461-01
26-461-02
26-461-03
26-461-04
22-119-02
22-119-03
SCP/AAP A, SCP 200, SCP 250
A ppendix B
Dimensions, Templates,
B
and Labels
Panel Dimensions
Templates
Labeling Buttons on the SCPs
