Dimensions, Templates, and Labels, cont'd
4. Cut the label strips to the appropriate length, and install
them in the SCP's windows.
For information about using the program, you can access a help
file by clicking on the Help menu on the main screen and
choosing Show Help.
You can also see an example of a completed Button-Label
Generator window by clicking on the Help menu on the main
screen, choosing Show Help, and clicking on the Load Demo
button.
The pictures below show how the Button-Label Generator
screens look when set for the SCP 200 and SCP 250.
SCP 200 button label screen
SCP 250 button label screen
Each input, display, and room control can be labeled with
names, alphanumeric characters, or bitmapped pictures. Each
button's label can contain from 1 to 3 lines of text (or none).
Each line provides a choice of font sizes and text placement.
Pictures can be selected either from the Device Palette or a user-
supplied graphic file. User-supplied graphics should be icon
(.ICO) or bitmap (.BMP) files. Files called TEST.BMP and
DEMO_BTN.DAT are installed with this program as examples.
B-10 SCP/AAP A, SCP 200, SCP 250 • Dimensions, Templates, Labels

Label templates

Below and on the following pages are full-sized templates for
the labels. Feel free to photocopy them, write button
information in each area of the blank templates as desired, cut
the strips out, and insert the strips in the label window(s).

SCP 200 labels

DISPLAY DISPLAY
POWER MUTE
DISPLAY DISPLAY
POWER MUTE
2 3
DISPLAY DISPLAY
POWER MUTE
2 3
SCP/AAP A, SCP 200, SCP 250 • Dimensions, Templates, Labels
1
MODE ROOM 1 ROOM 2
1
MODE ROOM 1 ROOM 2
4 5 6 7
1
MODE ROOM 1 ROOM 2
4 5 6 7
B-11
