- Page 1 User’s Manual PRELIMINARY SCP 250 Control Panel for Use With System Switchers 68-511-01 Rev. C 11 08...
- Page 2 Precautions Warning This equipment should be operated only from the power source This symbol is intended to alert the user of important indicated on the product. This equipment is intended to be used with a main power operating and maintenance (servicing) instructions in system with a grounded (neutral) conductor.
- Page 3 安全须知 中文 警告 该 设 备 只 能 使 用 产 品 上 标 明 的 电 源 。 设 备 电源 这个符号提示用户该设备用户手册中 必 须 使 用 有 地 线 的 供 电 系 统 供 电 。 第 三 条 线 有重要的操作和维护说明。...
- Page 5 Table of Contents Chapter One Introduction ............ 1-1 ..............1-2 ..................1-2 Chapter Two Installation and Operation ....2-1 ............... 2-2 ....2-2 ........2-4 ..................2-5 ........2-8 ............2-9 ......2-10 Appendix A Specifications, Part Numbers, Template, Labels ................A-1 ................A-2 ................A-3...
- Page 6 Table of Contents, cont’d...
-
Page 7: Chapter One
SCP 250 Chapter One Introduction About the SCP 250 Features... - Page 8 Introduction About the SCP 250 The system switcher cannot be configured from an SCP control panel. All switcher setup must be done from the switcher’s front panel or via RS-232. Features Black or white white faceplates System expandability Furniture and wall mountability...
-
Page 9: Chapter Two
SCP 250 Chapter Two Installation and Operation Installation Overview Preparing the Site, Installing the Electrical Box Rear Panel Connectors and Switches Cabling Front Panel Features and Operation Testing/Troubleshooting Mounting the SCP to the Electrical Box... -
Page 10: Installation Overview
Installation and Operation Installation Overview Preparing the Site, Installing the Electrical Box... - Page 11 3-gang wall box grounding.eps Wall Stud Screws or Nails Cable Clamp Foil Braided Shield Shield Installation Screw Cable...
-
Page 12: Rear Panel Connectors And Switches
To prevent short circuits, the outer foil shield can be cut back to the point where the cable exits the cable clamp. Connect both braided and foil shields to an equipment ground at the other end of the cable. Rear Panel Connectors and Switches SW13 SCP 250 Communications connectors... -
Page 13: Dip Switches
DIP switches 1, 2, 3, 4 5, 6, 7 DIP Switch Number Address For all switches *For switch 8 On each SCP in a system, switch 8 = closed (up) = System 7SC must be set to the correct position = open (down) = System 5cr Plus for the switcher model. - Page 14 E D C B A Ground (shield/drain) Comm. signal (white) To / from Ground (black) SCP 250 +12VDC (red) Wiring for use with a System 7SC switcher Conductor gauges in Extron Comm-Link cables Up to a total of 16 SCPs...
- Page 15 RELAY 1 RELAY 2 SENSOR System 7SC Rear Panel SW13 SW13 SW13 SCP 250 SCP 250 SW13 SW13 SCP 250 SCP 250 A daisy chain of SCPs connected to a System 7SC The maximum distance away from the switcher that the last SCP (or other device) in the daisy chain can be placed is 300 feet (91.4 meters).
-
Page 16: Front Panel Features And Operation
Installation and Operation, cont’d Front Panel Features and Operation DISPLAY AUDIO POWER MUTE MAX/ MODE VOLUME SCP 250 Display control buttons (Power, Mute, Mode) and LEDs Display power (Power) button and LED Display mute (Mute) button Mode button Volume control knob and LED... -
Page 17: Testing/Troubleshooting
IR signal pickup device Switcher configuration must be done using the front panel controls or RS-232 control. Configuration cannot be done from the IR 401 or IR 701. Room control buttons and LEDs System 5cr Plus User’s Manual System 7SC User’s Manual Input selection buttons and LEDs Testing/Troubleshooting... -
Page 18: Mounting The Scp To The Electrical Box
Cable D IO M IN D IS SCP 250 The SCP is shipped with a mounting bracket (mudring). However, for an installation that meets UL standards for safety, the SCP should be installed in a UL Listed electrical junction box, which must be purchased separately. - Page 19 SCP 250 A ppendix A Specifications, Part Numbers, Template, Labels Specifications Part Numbers Template Labeling Buttons on the SCP...
- Page 20 Specifications, Part Numbers, Template, Labels Specifications Control/remote — control panels General All nominal levels are at ±10%. Specifications are subject to change without notice. 7.6-102808-D4...
-
Page 21: Part Numbers
Part Numbers Included parts Included parts Replacement part number Accessories Accessories Part number Cables CTL Series (Comm-Link) cables Part number These cables are also available in 500 foot (150 m) lengths. Template... - Page 22 Cut-Out Template for Extron's SCP 250 4.50" (11.43 cm) 2.8" Top Panel (7.13 cm) SURFACE CUT-OUT AREA FOR FURNITURE MOUNT 6.40" (16.3 cm) Location of SCP 250 To install SCP 250 directly into furniture, cut along this line. TEMPLATE IS NOT FULL SIZE.
-
Page 23: Button-Label Generator Software
Labeling Buttons on the SCP ® Button-Label Generator software Installing the software System 7SC User’s Manual Using the software to make labels SCP 250... - Page 24 Specifications, Part Numbers, Template, Labels Use Help SCP 250 button label screen Label templates...
- Page 26 Specifications, Part Numbers, Template, Labels...
- Page 27 fitness for any particular use. In no event will Extron Electronics be liable for direct, indirect, or consequential damages resulting from any defect in this product even if Extron Electronics has been advised of such damage.
- Page 28 Inside USA / Canada Only Inside Europe Only Inside Asia Only Inside China Only Inside USA / Canada Only +1.919.863.1794 +31.33.453.4040 +65.6383.4400 +86.21.3760.1568 +1.714.491.1500 +1.919.863.1797 FAX +31.33.453.4050 FAX +65.6383.4664 FAX +86.21.3760.1566 FAX +1.714.491.1517 FAX © 2008 Extron Electronics. All rights reserved.
