Installing the MSA SAN Switch 2/8
1. If the MSA SAN Switch is replacing the provided Modular SAN Array Fibre
Figure 4: Removing the Fibre Channel I/O Module
Note:
be re-used in the MSA SAN Switch. See
handling SFPs.
2. Remove the MSA SAN Switch from its protective bag.
24
Channel I/O Module in the primary slot of the MSA1000, remove the I/O
Module from the bay.
To remove the I/O module, slide and hold the latch on the I/O Module to the
right and then grasp the handle and pull the I/O Module straight out of the bay.
See Figure 4 for an illustration.
Carefully remove and save the SFP from the Fibre Channel I/O Module; it can
"Installing an SFP Module" for information on
MSA SAN Switch 2/8 Installation Guide
