Pin assignment

PARALLEL REMOTE terminal
Modular connector
(8-pin)
Pin number
Functions
1
Set input signal LINE A
2
Set input signal LINE B
3
Set tally lamp on or off
4
Select underscan
5
GND
6
Set blue only on or off
7
Select aspect ratio 16:9
8
Select external sync
You can allocate functions using the REMOTE menu.
Wiring required to use the Remote Control
Connect the function you want to use with a Remote
Control to the Ground (Pin 5).
1
8
33
