560H Series Connector Conforming to Ver. 4
RIGHT-ANGLE PLUG, THROUGHHOLE TYPE (WITH RIGHT-BUTTON EJECTOR, TO BE
MOUNTED ON THE BACK OF THE PC BOARD) SUPPORTS TYPE I, II CARDS
DIMENSIONS
Part number: FCN-565P068-G/XF-V4 (Button color: Black)
Part number: FCN-565P068-G/PF-V4 (Button color: Beige)
7 (0.276)
2.5
4.8 (0.189)
PC BOARD MOUNTING HOLE LAYOUT (MOUNTING SIDE)
50.8 (2)
1.27 (0.05)
(68/2-1) = 41.91 (1.65)
1.27 (0.05)
±0.05 (0.0020)
No.34
±0.05 (0.0020)
34 (1.339)
67.31 (2.65)~68.0 (2.677)
Unit: mm (in.)
Specifications
subject to change
67.31 (2.65)
59.7 (2.35)
50.8 (2)
34 (1.339)
10 (0.394)
78.5 (3.091)
59 (2.323)
42 (1.654)
35.5 (1.398)
No.68
No.35
No.34
No.1
±0.1 (0.0039)
±0.1 (0.0039)
No.35
No.1
Ejector button
Dimensions are in millimeters (inches)
2.5mm (0.098)
deep spot facing
MOUNTING EXAMPLE
Regardless of how the connector is mounted on the PC
board, a card can be inserted with its face upward.
www.fcai.fujitsu.com
Unit: mm (in.)
Nut buried
9
