560H Series Connector Conforming to Ver. 4
RIGHT-ANGLE PLUG, THROUGHHOLE TYPE (WITH NO EJECTOR, WITH GUIDE )
SUPPORTS TYPE I, II CARDS
DIMENSIONS
Part number: FCN-565P068-G/C34-V4
3 (0.118)
*A 60.48 mm (2.381 in.) model is also available. FCN-565P068-G/C32-V4
PC BOARD MOUNTING HOLE LAYOUT (MOUNTING SIDE)
±0.05 (0.0020)
5.715 (0.225)
3.810 (0.15)
1.905 (0.075)
Specifications
subject to change
7
(0.276)
No.35
50.8 (2)
1.27 (0.05)
= 41.91 (1.65)
No.1
1.27 (0.05)
±0.05 (0.0020)
No.35
±0.05 (0.0020)
Dimensions are in millimeters (inches)
59.7 (2.35)
2.5mm (0.098)
deep spot facing
50.8 (2)
59 (2.32)
No.1
No.34
No.68
±0.1 (0.0039)
(68/2-1)
±0.1 (0.0039)
No.34
±0.05 (0.0020)
2- ø 2.8 (0.110)
68- ø 1 (0.039)
No.68
www.fcai.fujitsu.com
Unit: mm (in.)
±0.1 (0.0039)
±0.05 (0.0020)
Unit: mm (in.)
6
