560H Series Connector Conforming to Ver. 4
RIGHT-ANGLE PLUG, THROUGHHOLE TYPE (WITH RIGHT-BUTTON EJECTOR)
SUPPORTS TYPE I, II CARDS
DIMENSIONS
Part number: FCN-565P068-G/XC-V4 (Type I, II Card, Button color: Black)
Part number: FCN-565P068-G/XC-4V (Type I, II, III Card, Button color: Black)
Part number: FCN-565P068-G/PC-V4 (Type I, II Card, Button color: Beige)
7 (0.276)
3 (0.118)
4.8 (0.189)
A model with an FG accessory for ESD protection is also available. Specify part number FCN-565P068-G/C23-E4,
instead of FCN-565P068-G/XC-V4.
PC BOARD MOUNTING HOLE LAYOUT (MOUNTING SIDE)
Specifications
subject to change
67.31 (2.65)
59.7 (2.35)
50.8 (2)
34 (1.339)
10 (0.394)
78.5 (3.091)
59 (2.323)
42 (1.654)
35.5 (1.398)
No.1
No.17
No.18
No.34
No.35
No.51
No.52
No.68
50.8 (2)
±0.1 (0.0039)
No.1
41.91 (1.65)
±0.1 (0.0039)
No.2
±0.05 (0.0020)
1.27 (0.05)
No.3
No.68
±0.05 (0.0020)
34 (1.339)
67.31 (2.65)~68.0 (2.677)
(Card insertion side)
Dimensions are in millimeters (inches)
2.5mm (0.098)
deep spot facing
±0.1 (0.0039)
www.fcai.fujitsu.com
Unit: mm (in.)
Unit: mm (in.)
7
