560H Series Connector Conforming to Ver. 4
STRAIGHT PLUG, THROUGHHOLE TYPE (WITH NO EJECTOR)
DIMENSIONS
Part number: FCN-564P068-G/0-V4
5.715 (0.225)
1.905 (0.075)
7 (0.394)
No.1
No.35
• A model with the feature of preventing mismated board mounting is available. Contact Fujitsu.
PC BOARD MOUNTING HOLE LAYOUT (MOUNTING SIDE)
No.1
No.2
Specifications
subject to change
Polarization Post
74 (2.91)
66.04 (2.6)
50.8 (2)
41.91 (1.65)
1.27 (0.05)
59.7 (2.35)
41.91 (1.65)
1.27 (0.05)
No.17
No.34
No.51
No.68
66.04 (2.6)
0.1 (0.0039)
41.91 (1.65)
0.1 (0.0039)
0.05 (0.0020)
1.27 (0.05)
No.3
No.68
Dimensions are in millimeters (inches)
Unit: mm (in.)
Unit: mm (in.)
www.fcai.fujitsu.com
19
